Section 10 — Exploded Views and Parts Lists
PRIMEPACT 70G and 70LP Recreational Vehicle Generators
Alternator and Panel - Drawing No. 0D3463
TEM PART NO. QTY. DESCRIPTION
ITEM PART NO. QTY. DESCRIPTION
1
C9675
1
LOWER BEARING CARRIER
30
75476
4
M4-0.7X 16LG. CAPSCREW
2
80095H
1
ROTOR ASSEMBLY
31
22264
6
#8/ M4-LOCK WASHER
3
92848H
1
STATOR ASSEMBLY
32
38077
1
CIRCUIT BRACKER 15A.
4
73159
1
BALL BEARING
33
90987
2
M3-0.5X 12LG. PPHMS
5
31971
1
BALL BEARING
34
86317A
1
PANEL SUPPORT BRACKET
6
C9674
1
UPPER BEARING CARRIER
35
75235
4
M5-0.8X30 LG. CAPSCREW
7
77006
4
STUD-STATOR
36
82737
4
VIBRATION MOUNT
8
52858
4
M8-1.25 FLANGE LOCK NUT
37
49813
4
M6-1.0 HEX NUT
9
66386
1
BRUSH HOLDER
38
49815
1
M5-08X 16LG.HEX HD. CAPSCR.
10
66849
2
M5-0.8X 16LG.TAPT1TE
39
43182
2
M3-LOCK WASHER
11
27756
4
NYLON WASHER
40
45771
4
M8-1.25 HEX NUT
12
86314
1
GENERATOR TOP HOUSING
41
54502
1
C/BREAKER 3.0A
13
A8475
3
M5-SPECIAL LOCK WASHER
42
90157
1
DECAL, CB RATING 30A.
14
D2724
2
BOOT, ROCKER SWITCH
43
83049
1
REGULATOR VOLTAGE
15
22097
4
'/47
M6-LOCK WASHER
44
22152
6
M5-LOCK WASHER
16
31791
1
CLAMP, HOSE
45
51716
4
M5-0.8 HEX NUT
17
90141
2
GROUND CABLE
46
51715
1
M4-0.7 HEX NUT
18
A1658
1
M6-SPECIAL LOCK WASHER
47
82081
1
C/BREAKER 30A.
19
74906
4
M6-1.0X20 LG.TAPTITE
48
25105
4
#6-32
X
'A" SCREW W/LOCK WASHER
20
92234
1
CONTROLLER P.C.B.
49
86315
1
PANEL COVER
21
93846
1
DECAL, CUSTOMER CONN.
50
90734
4
M4-0.7
X
12 LG, CAPSCR.W/LOCK-
22
22129
4
5/167 M8 LOCKWASHER
WASHERS FLAT WASHER
23
23484-S
1
BUSHING
51
22985
3
#6-FLAT WASHER
24
86316A
1
PANEL SHEET METAL
52
32300
1
FUSE HOLDER
25
53650
1
4-PIN CONNECTOR
53
22676
1
FUSE AGC-15A,
26
C4887
1
SEALTITE CONDUIT ASSEMBLY
54
87798
1
SWITCH S.P.D.T. 6A.-(START-STOP)
27
75244
1
ASSEMBLY, REMOTE CABLE
55
92113
1
SWITCH S.PD.T.-(FUEL PUMP)
28
74908
1
M5-0.8X10LONGTAPTITE
56
75210-A
1
TERMINAL BLOCK
29
23897
1
#10/M5-FLAT WASHER
57
A8475-A
1
#8 SPECIAL LOCK WASHER
Generac* Power Systems, Inc. 45
