Section 10 —
Exploded Views
and Parts Lists
PRIMEPACT 70G and 70LP Recreational Vehicle Generators
Base and Pulleys - Drawing No. 0D3464A
FEM PART NO. QTY.
DESCRIPTION
ITEM PART NO. QTY.
DESCRIPTION
1
086318
1
BASE, MOUNTING
50
043790A
1
ELBOW-3/8" NPT x 3/8"
2
022145
4
FLAT WASHER 5/16" -M8
51
047290
1
HOSE-3/8" I.D. #6L0LA
3
046911
4
MOUNT, (RUBBER)
52
035461
1
FITTING, BARBED-1/4" NPT
4
025017
8
CAPSCREW, HEX HD.-3/8"-6 x 1/2"
53
069811
1
CAP, HEX-1/4" NPT
5
022237
6
LOCKWASHER-3/8"
54
092120
2
NUT LOCK TRIG M6-1.0Y/ZNC
6
022129
8
LOCKWASHER5/16" -M8
55
087769
1
FILTER, FUEL
7
072391
2
SKID, RUBBER MOUNT
56
073179
1
OIL FILTER SUPPORT
8
077603
2
SAFETY BOLT, 5/16"-18x 3-1/2"
57
070185
1
FILTER, OIL(FRAM#PH3614)
9
022259
2
NUT, HEX -5/16--18
58
0A8584
1
10 PSI-SWITCH, OIL PRESSURE
10
052858
6
NUT FLANGED LOCK-M8-1.25
59
074948
3
FiniNG-5/16"
11
051730
2
CAPSCR, HEX HD.-M8-1.25 x 60mm
60
074950
1
TUBE, OUTER OIL
12
029459
2
SPRING, BELT TENSION
61
074951
1
TUBE, INNER OIL
13
075215
2
WASHER, SPRING CNTR,
62
073134
1
ADAPTOR, OIL FILTER ADAPTER
14
073146
4
SLIDE (NYLON)
63
038750
3
CAPSCREW, HEX HEAD
15
075209
2
SUPPORT, NYLON SLIDE
M6-1.00 X 30mm
16
073174
1
MANIFOLD, EXHAUST
64
074949
1
FITTING, 90-DEGREE-5/16”
17
079678
2
RING, SEALING
65
068548
1
GASKET, OIL FILTER ADAPTER
18
040976
4
SHCS, M8-1,25 x 20mm
66
0C4006
1
CABLE, BATTERY
19
072383
2
GASKET, COLLECTOR PAN
67
029289
-
TAPE, FOAM-1/16”THICKx8’
20
023897
6
FLAT WASHER #10-M5
68
087770
1
LINE, FUEL
21
075224-G
1
PULLEY, ENGINE
69
075281
1
SWITCH, HIGH TEMPERATURE
22
073106-G
1
PULLEY, ALTERNATOR
70
OC1085
2
SCREW, PAN HEAD-M3-0.50 x 8mm
23
075216
1
BELT (POLY V 4L)-40”
71
043182
2
LOCKWASHER-M3
24
049451
1
WASHER, PULLEY RETAINER
72
090088
1
CLAMP, VINYL COATED
7GA, ,41"x1,62"
73
075237
4
WASHER, SPRING RETAINER
25
042633
1
HHCS, 3/8”-24x1" (GRADES)
74
0D1624
1
BOOT, OIL PRESSURE SWITCH
26
077017
1
GUIDE, BLOWER HOUSING
75
075474
1
BOOT, TEMPERATURE SWITCH
27
073118
1
CAPSCR,, HEX HD,-3/8"-24 x 2-1/4"
76
090800
1
ELBOW, EXHAUST -UNIVERSAL
28
074906
10
TAPTITE, M6-1,00x20mm
77
094670
1
CLAMP, EXHAUST
29
022152
2
WASHER, LOCK #10
78
075226
1
COVER, AIR
30
072375
1
HOUSING, BLOWER
79
056893
22
CRIMPTITE, NO. 10-24
X
1/2"
31
073185
1
SPACER, BLOWER HOUSING 2-3/8”
80
075229
1
GASKET, SLIDE PAN
32
022097
6
LOCKWASHER 'A" -M6
81
0D3158
1
SLIDE PAN
33
077682
1
CAPSCR. HEX HD.-M5-0.80 x 80mm
82
079246
8
CAPSCREW, HEX HEAD
34
075242
4
SPRING, GENERATOR SET MT
M6-1.00X 16mmWITH LOCKWASHER
35
049813
2
NUT, HEX M6-1.0
83
022473
7
FLATWASHER, H" -M6
36
045757
2
CAPSCREW, HEX HEAD- M6-1.0 x 25mm
84
090475
!
PUMP FUEL
37
090859
1
COVER PLATE
85
072384-C
1
COVER, EXHAUST OUTLET
38
048031-E
2
CLAMP, HOSE-3/8"
86
022131
1
FLATWASHER, 3/8" -M10
39
091123
1
BRACKET, FUEL PUMP
87
077643
1
GASKET, EXHAUST OUTLET
40
045756
9
TAPTITE, M6-1,0x10mm
88
0A8475
1
SPECIAL LOCKWASHER, M5
41
081105
2
5/16-18 FLANGE NUT, SPECIAL
89
090141
1
GROUND CABLE
42
087768
1
FITTING, 1/8" PIPE TO 'A" TUBE
90
0A1658
3
SPECIAL LOCK WASHER, W"
43
07571OA
1
TUBE, OIL FILL AND DRAIN
91
045756
1
TAPTITE, M6-1.00x10mm
44
074958
1
CAP & DIPSTICK ASSEMBLY
92
ODI 227
1
CONTACTOR, STARTER
45
067871
1
O-RING, CAP
93
0133-74260
1
CABLE, STARTER
46
0A5508
1
OIL FILL TUBE GASKET
94
024414
2
HEX NUT, 5/16”-24 STEEL
47
075711
1
PIPE, OIL DRAIN ADAPTOR
95
0D1741A
1
BOOT, BATTERY CABLE
48
022413
1
CAPSCR., HEX HD.-1/4-20X1"
96
0D1741
2
BOOT, BATTERY CABLE
49
0A5802
1
TINNERMAN CLIP
97
022158
2
HEX NUT, #10-32 STEEL
Generac® Power Systems, Inc. 43
