Section 7 — Exploded View s and Parts Lists
Guardian Air-cooled 6 kW, 8 kW and 10 kW Generators
Mounting Base Assembly - Drawing No. C2372-
TEM
PART NO.
QTY. DESCRIPTION
ITEM
PART NO.
QTY. DESCRIPTION
1
Cl 753
1
ALTERNATOR PULLEY
21
C1751
1
ALTERNATOR FAN MODEL-
2
A9628
1
ASSEMBLY, ENCLOSURE
04077, 04109 (7”)
BASE
Cl 752
1
ALTERNATOR FAN MODEL-
3
C1112
1
V-BELT
04079 (8”)
4
75224D
1
ENGINE PULLEY
22
22131
5
3/8" FLAT WASHER
5
38353
4
RUBBER MOUNT
23
22237
4
3/8" LOCK WASHER
6
A9593
1
EXHAUST DUCT ASSEMBLY
24
23152
4
3/8"-16
X
%" HEX HEAD BOLT
7
A9827
1
BLOWER HOUSING
25
22241
1
3/8-16 NUT
8
Cl 441
1
GASKET SET, BLOWER
26
22145
3
5/16 FLAT WASHER
HOUSING
27
22129
3
5/16 LOCK WASHER
9
22473
5
M6 FLAT WASHER
28
55173
3
M8-1.25
X
20 HEX HEAD
10
22097
2
M6 LOCK WASHER
29
79246
3
M6-1.0
X
16 HEX HEAD WITH
11
22287
2
74-20
X
W HEX HEAD
LOCK WASHER
12
C2824
7
TAP-R 10-32
X
9/16"
30
49451
1
7GA.
X
.41"
X
1.62" FLAT
13
26307
1
90DEG. STREET ELBOW-3/4"
WASHER
14
C2206
1
BARBED HOSE FITTING
31
22237
2
3/8" LOCK WASHER
15
74994
2 FT. 72" I.D. HOSE
32
42633
1
3/8"-24
X
1" HEX HEAD
16
57822
2
HOSE CLAMP #8
33
73118
1
3/8"-24x 2-1/4" HEX HEAD
17
63463
1
BARBED HOSE FITTING
34
C2417
1
GROUND STRAP
18
C1616
1
8/10 KW LOAD BLOCK
35
A4456
1
3/8" LOCK WASHER-SPECIAL
C1616B
1
6 KW LOAD BLOCK
36
A1658
2
74" LOCK WASHER-SPECIAL
19
75211
1
GAS REGULATOR
37
49813
1
M6-1.0 NUT
20
C2131
1
GASKET SET, AIR DUCT
38
AB38805
1
CABLE, BLACK-BATTERY
39
A2311
1
74"-20
X
1" FASTENER
3S
