Section 7 — Exploded View s and Parts Lists
Guardian 8 kW and 10 kW Generators
GN-724 Engine Accessories and Sheet Metal - Drawing No. C2371-
..PARTS
LISTS
TEM
PART NO.
QTY. DESCRIPTION
ITEM
PART NO.
QTY. DESCRIPTION
1
Cl 350A
1
WRAPPER, VALLEY
41
56893
29
10-24
X 1/2
"CRIMPTITE
2
C1351A
1
WRAPPER, CYLINDER #1
42
A2311
2
1/4-20
X
1" TAPTITE
3
Cl 354A
1
STARTER, WRAPPER
43
Cl 349
1
SCROLL, FLYWHEEL
4
C1353A
1
WRAPPER, CRANKCASE
44
Cl 677
1
GOVERNOR BRACKET
5
Cl 355
1
10KW COVER, ENGINE
45
Cl 676
1
GOVERNOR LEVER
C1355A
1
8KW COVER, ENGINE
46
C1679
1
GOVERNOR LINKAGE
6
Cl 352A
1
WRAPPER, CYLINDER
47
Cl 680
1
SPRING, ANTI-LASH
#2-BACK
48
Cl 859
1
SPRING, IDLE
7
Cl 468A
1
WRAPPER, CYLINDER
49
22097
16
1
/
4
"
LOCK WASHER
#2-FRONT
50
22717B
1
GROMMET
8
66480
1
GASKET, AIR CLEANER
51
22717A
1
GROMMET
9
Cl 460
1
CARBURETOR
52
22127
2
1
/
4-20
HEX NUT
10
Cl 285
1
MANIFOLD INTAKE
53
C2420
1
KEY
11
Cl 625
2
GASKET, INTAKE
54
65852
1
CLIP
12
C2784
1
TUBE, INTAKE
55
C2441
1
WIRE DIODE ASSEMBLY
13
35685
1
CLAMP, #28
56
Cl 863
1
BAFFLE
14
70941
1
FILTER, AIR
57
36261
2
POP RIVET, 1/8"
X
.23 S.S.
15
Cl 626
1
GASKET CARBURETOR
58
22129
6
5/16" LOCK WASHER
16
C2689
4
M6-1.0
X
16 SOCKET
59
C2693
1
CARRIAGE BOLT V4-20 x 1-3/8"
HEAD SCREW
60
49811
1
M6 FLAT WASHER
17
39287
2
M8-1.25
X
45 HEX HEAD BOLT
61
91159
2
RUBBER BUSHING
18
A9736
1
FRAME, 10KW
62
74962A
1
SPRING, GOVERNOR
A9736A
1
FRAME, 8KW
63
C2145
1
GASKET, SET ENGINE COVER
19
22287
2
Y4-20
X
3/4" HEX HEAD BOLT
64
74902
2
SHIELD WRAPPER
20
C2421
1
ROD, SPEED CONTROL
65
38593
1
90 DEG.ST. ELBOW 3/8"
21
C2425
1
BRACKET, SPEED CONTROL
66
Cl 983
1
3/8"
X
11-1/4" PIPE
22
C2424
1
CAP, SPRING
67
A7299
1
DIPSTICK TUBE
23
C2422
1
SPRING, SPEED CONTROL
68
A8875
1
DIPSTICK & CAP
24
C2423
1
NUT, SPEED CONTROL
69
43790A
1
90 DEG. HOSE FITTING
25
74908
4
M5-0.8
X
10 TAPTITE
3/8"
X
3/8"
26
22413
4
1/4-20
X
1" HEX HEAD BOLT
70
C2078
1
OIL DRAIN HOSE
27
Cl 702
1
BREATHER HOSE
71
75246
4
3/8-16
X
1-1/4" TAPTITE
28
A9027
1
OIL ADAPTOR
72
A4456
1
3/8" SPECIAL LOCK WASHER
29
A9028
1
OIL ADAPTOR BOLT
73
A9820
1
EXHAUST MANIFOLD
30
Cl 557
1
0-RING, 13/16" I.D.
74
Cl 624
2
EXHAUST GASKET
31
Cl 547
1
0-RING, 7/8"
75
75789
4
5/16-18
X
%" SOCKET
32
Cl 546
1
0-RING, 2-3/8"
HEAD SCREW
33
74948
4
FITTING, 5/16" COMPRESSION 76
Cl 950
2
GASKET, EXHAUST
34
Cl 623
1
OIL TUBE, RETURN
77
23897
6
#10 FLAT WASHER
35
Cl 622
1
OIL TUBE, OUT
78
23762
1
STAR WASHER #10
36
A6898
1
OIL FILTER SUPPORT
79
73132
2
BOOT, SPARK PLUG
37
70185
1
OIL FILTER
80
C2866
1
CLAMP
38
60108
1
OIL PRESSURE SWITCH
81
A9816
1
EXHAUST FLEX
39
11-74260 1
STARTER CABLE
82
C2418
1
NUT, FLYWHEEL
40
22507
6
1/4-20
X
i/z" HEX HEAD BOLT
83
C2419
1
WASHER, FLYWHEEL
84
C2824
1
TAP-R 10-32
X
9/16"
Generac® Power Systems, Inc. 33
