PARTS LIST FOR MODEL 310-430A
REF. PART COLOR
DESCRIPTION
NEW REF. PART COLOR NEW
NO. NO. CODE PART NO. NO. CODE DESCRIPTION PART
1 05506 Drive Clutch Grip Ass’y. 32 748-0233 Shoulder Spacer
2 01166 Grip 33 736-0231 FI-Wash. .34I.D. xl.12
4 711-0415 Clevis Pin .375 Dia. x 1.62 O.D. X .125
Lg. 34 736-0119 L-Wash. 5/16” Scr.*
5 711-0677 Adjustment Ferrule 35 712-0158 Hex Cent. L-Nut 5/16-18
6 725-0201 Ignition Key Thd.
7 725-0464 ignition Switch 36 05811 Shifting Bracket N
8 736-0225 Internal L-Wash. 5/8” Scr.* 37 714-0111 Cotter Pin 3/32” Dia. x 1.00
9 746-0312 Throttle Control Ass’y- Lg.
10 710-0227 Self Tap. Scr. #8x .50” Lg. 38 736-0159 FI-Wash. .344I.D.X.88
11 Curved Carriage Bolt O.D. X .063
T«-5yi 5/16-18x«BI/-75lia- 39 749-0204 Handle—R.H.
12 05507 Auger Clutch Grip Ass’y. 40 05559 Thrower Clutch Bracket
13 726-0110 Push Cap .375” Rod—Black 41 712-0324 Hex Ins. L-Nut V4-20 Thd.
14 736-0242 Belleville Wash. 42 736-0173 FI-Wash. .28 I.D. x .75 O.D.
15 712-0267 Hex Nut 5/16-18 Thd.* 43 747-0175 Shifting Rod
16 736-0140 FI-Wash. .385I.D. X.62 44 746-0374 Drive Clutch Control Cable N
O.D.
X
.060 45 725-0480 Vinyl Sealing Tape
17 720-0171 Black Knob—3/8” Dia. Hole 46 725-0476 Electric Wire
18 726-0100 Push Nut 3/8” Rod 47 710-0458 Carriage Bolt 5/16-18 x
19 747-'0t53^1w Chute Crank 1.75” Lg.*
20 05567 Auger Clutch Rod Ass’y. 48 712-0116 Hex Ins. Jam L-Nut 3/8-24
21 05516 Chute Control Bracket Thd.*
22 732-0337 Compression Spring .39 O.D. 49 732-0193 Compression Spring .60
X .75” Lg. O.D.
X
.88” Lg.
23 749-0203 Handle—L.H. 50 736-0105 Belleville Wash. .40 I.D. x
24 05816 Handle Panel Ass’y. N .88 O.D.
25 747-0154 Lockout Rod .214 Dia. x
26
32.0” Lg.
Pilot Scr. 3/8-16 xBl’Lg. 52 05694 Shift Handle Ass’y.
27 73^1^ L-Wash.3/8” Scr.* 53 05^ Cable Support Bracket
28 732-0320 Extension Spring .38 O.D.
X3.25 Lg. 55 t TO b He)^el^^^c^7W^
29 710-0600 Hex Wash. Hd. Self Tap Scr. .75” Lg.
5/16-24
X
.50” Lg. 56 726-0195 “U”-Nut 3/8-16 Thd. N
30 05790 Frame Cover N 57 Hex Jam Nut 5/16-24 Thd.
31 710-0322 Hex Sems Scr. 5/16-18 x
1.00” Lg.*
'For faster service obtain standard nuts, boits and washers localiy. if these items cannot be obtained locaiiy, order by part
number and size as shown on parts list.
(488—Mack Truck Yellow) When ordering parts if color or finish is important, use color code shown at left. (e.g. Mack
Truck Yellow Finish—05546 (488).)
The engine is not under warranty by the Snow Thrower
manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine
service
outlet. Check the “Yellow Pages” of your
telephone book under “Engines—Gasoline.”
Find It Fast
In The
Yellow Pages
NOTE
This instruction manual covers various
models and all specifications shown do not
necessarily
apply to your model. Specifica­
tions subject to change without notice or
obligation.
21
