_______________ REPAIR PARTS — ENGINE SHEET METAL
Drawing No. A9194 Rev. A
ITEM PART NO. QTY. DESCRIPTION
1
86705
1
2
49813
2
3
86718
3.5 FT.
4
A3666
1
5
74908
33
6
A3667
2
7
22129
12
8
39414
4
12
89680
1
13
94670
1
17
89471
1
18
86731A
1
19
86715
1
20
86726
1
21
86671
1
22
86727
1
23
86719
1
24
20519
1
25
90141A
1
26
86724
1
27
90475
1
28
28740
1
29
22127
3
30
22097
7
31
86729
1
32
90518
1
33
89048
1
34
90537
1
35
22145
4
36
30340
1
37
48031C
5
38
23484D
1
39
23762
2
40
22471
2
41
22264
2
42
79246
2
PLATE, DIVIDER
M6-1.0 HEX NUT
SEAL RUBBER EXTRUSION
WRAPPER, BOX
TAPTITE, M5-.8 X 10MM LG.
MOUNTING BRACKET
M8 LOCK WASHER
M8-1.25 X 35MMHEX HD.
CAPSCREW
SPARK ARRESTOR
CLAMP, EXHAUST
DEFLECTOR, AIR OUT
ASSEMBLY, MUFFLER
HOUSING, LOWER FAN
SKIRT, CARS. BAFFLE
COVER, ROCKER COVER
SKIRT, SPARK PLUG SIDE
PAN, BELLY
FRAME
GROUND STRAP
PLATE, BASE COVER
PUMP, FUEL
BARBED 90 1/8” X 1/4"
HEX NUT, 1/4"-20
LOCK WASHER-1/4”/M6
CONTACTOR, STARTER
BOOT, CONTACTOR
SEAL, OIL FILTER HOLE
RETAINER, SEAL
M8 FLAT WASHER
1/4” FUEL LINE - 4” LONG
1/4" HOSE CLAMP
SNAP BUSHING
EXTERNAL SHAKEPROOF
#8 HEX NUT
#8 LOCK WASHER
H.H.CPSCR., M6-1.0X16MM
W/LOCKWASHER
ITEM
PART NO.
QTY.
DESCRIPTION
44
22447
3
WASHER, INT. SHAKEPROOF,
1/4”/M6
45
103-74260
1
GROUND STRAP, UNIT
47
39450
1
1/8” X 3/16” NPT 90° BARBED
FITTING
48
92000
1
BRCKT., MUFFLER HANGER
49
30340
1
1/4” FUEL LINE (8” LONG)
50
82580D
1
3/16” CARB. LINE (4” LONG)
51
86311
1
FUEL FILTER
53
007-91297
1
STARTER CONTACTOR
GROUND WIRE
54
89045
1
SEAL, WASHER EXH. PIPE
57
A3638
1
PANEL, WRAPPER BOX
59
56893
11
CRIMPTITE, #10-24X1/2”
60
A5767
1
HEX HD. CAPSCREW,
M5-0.8 X 6MM
61
A3764
2
CUSTOMER MNTG. BRCKT.
62
66443B
4
VIBRATION MOUNT
63
20668
2
EARTHING STRAP
64
45771
8
HEXNUT-M8
65
38353
3
VIBRATION MOUNT
67
79119
2
TAPTITE 1/4”-20 X 1-1/4”
68
A7213
2
TAG, REMOVE BOLT
69
23897
4
FLAT WASHER #10/M5
70
A9172
1
BRACKET, IGNITION SYS.
71
89047
2
SPACER, IGNITION COIL
72
86711
1
MODULE, IGNITION
73
89049B
1
ASSY., IGNITION COIL
74
49721
2
M6-1.0X35MM H.H. CAPSCR.
75
49813
4
M6-1.0HEXNUT
76
91526
2
M5-0.8X 12MM PPHMS
77
51716
2
M5-0.8 HEX NUT
78
49226
2
LOCK WASHER, M5
79
84867
.25 FT.
RUBBER “U" CHANNEL
80
56892
1
CRIMPTITE #10-24X3/8”
81
A9196
1
COVER, IGNITION SYSTEM
- 4 3 -
