_______________ REPAIR PARTS — ENGINE LONG BLOCK
Drawing No. A6202 Rev. B
date
:
aug
.
io
, 1998
ITEM
PART NO.
QTY.
DESCRIPTION
1
76380
1
ASSEMBLY, CONNECTING ROD & CAP
2
76389
1
PISTON PIN
3
88411
1
SET. PISTON RING (STD. SIZE)
4
72657
2
PIPE PLUG-1/4 NPT
5
77176
1
COVER. BREATHER
6
88057
1
PISTON, 75 DIA.
7
76390
2
RETAINER, PISTON PIN
8
21860
1
ASSEMBLY, CRANKSHAFT AND GEAR
10
89923
1
SEPARATOR, OIL BREATHER
11
89213L
1
ASSEMBLY, CRANKCASE
13
81695
2
SEAL, OIL-CRANKSHAFT
14
90604
1
CUP, BREATHER BAFFLE
17
78699B
3
SLEEVE. DOWEL 0 12
18
A2477
1
ASSEMBLY. CAMSHAFT
19
89096
1
GASKET, CRANK CASE FLANGE
21
A8822
1
GASKET. CYLINDER HEAD
22
78691
1
RETAINER, OIL PRESSURE SPRING
23
A5772
1
SPRING, OIL PRESSURE
24
A5776
1
BALL, OIL PRESSURE
25
74908
1
TAPTITE, M5-0.8
X
10
26
78606
4
SCREW & LOCK WASHER, M6-1 x 12 LONG
28
89230
6
HHFC, M8-1.25X35LONG
30
A1720
2
RETAINER, VALVE SPRING
31
88401
2
SPRING, VALVE
32
88590
1
DOWEL PIN, DIA. 12 x 18 LONG
33
83152
1
GEROTOR, INNER
34
76381
2
BOLT, CONNECTING ROD
36
21705B
1
ASSEMBLY, CYLINDER HEAD W/GUIDES & SEATS
37
90082
1
VALVE. EXHAUST
38
90081
1
VALVE, INTAKE
39
88396A
2
PUSH ROD
40
83235
2
TAPPET
42
96362
1
GASKET, ROCKER COVER
43
77161
2
STUD, BALL PIVOT
44
77160
2
ROCKER ARM
45
76307
2
NUT, ROCKER ARM
46
88403
1
PLATE, PUSH ROD GUIDE
47
77168
5
HEADBOLT, M8 x 52MM
48
88413B
1
COVER, ROCKER
49
78629
2
GASKET, BREATHER
50
90388
2
BOLT, TAPTITE-M6
X
12 LONG
5J
83153
1
GEROTOR. OUTER
52
92977
1
ASSEMBLY-SUMP, OIL
53
84186
2
WASHER, WEAR-VALVE SPRING
54
88156
1
SEAL VALVE-INTAKE
58
72347
1
SPARK PLUG, CHAMPION RC12YC
59
99922
1
WASHER, SPRING
