I
REPAIR PARTS — GENERATOR
Drawing No. A5969 Rev. A
ITEM PARTNO l .. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 A2467 ENGINE, LONG BLOCK 55 52618 5 M5-0.8X 12MM CPSCR.
2 94583 1 FLYWHEEL, FAN 56 005-91297 1 • OIL PRESS. SWITCH WIRE
3 83312 2 WASHER, CONICAL 57 42907 3 HEX HD. CAPSCREW,
4 81810 2 HEX NUT, Ml6-1.5 M8-1.25X 16MM
5 70185 1 FILTER, OIL 58 22129 10 LOCKWASHER - M8
6 86730 1 TUBE, EXHAUST OUTLET 59 74906 4 M6-1 X 20MM TAPTITE
7 89476 • 1 GASKET, EXHAUST 61 39253 3 HEX HD. CAPSCREW,
8 40976 4 SOCKET HD. CAPSCR., M8-1.25X20MM
M8-1.25X20MM 62 22511 3 HEX HD. CAPSCREW,
9 99948 1 STARTER, EATON/GENERAC 3/8”-16X 1.25”
11 86705 1 PLATE, DIVIDER 63 22237 3 LOCKWASHER - 3/8”
12 22097 8 LOCKWASHER, 1/4”-M6 64 55822 2 PHMS, M4-.7 X 8MM
14 92059 1 STEPPER MOTOR SPEED 65 22264 2 LOCKWASHER - M4
CONTROL 66 89050 2 PPHMS - M6-1 X 90MM
15 86706 1 ROD, THROTTLE CONTROL 67 82774 1 WOODRUFF KEY-
16 89477 1 CLIP, ADJUSTMENT 4MMX 19MM
17 89478 1 SNAP, RETAINING 68 59637 4 TAPTITE 3/8”-16 X .75"
18 90192 1 WASHER, CARBURETOR 69 86697 1 ASSY. IGNITION SENSOR
19 90881A 1 ASSEMBLY., CARBURETOR 70 86704 3 SPACER, ENGINE MOUNT
20 90051 2 GASKET, 71 86701 1 BRCKT., ENG. MNT. FRONT
CARB./SPACER/HEAD 72 86702 1 BRCKT., ENG. MNT. REAR
21 78631 1 GASKET, CARB./SKIRT 73 38353 3 RUBBER MOUNTS
22 96459 1 GASKET, CARB./INLET 74 89263 1 ASSY., OIL FILL CAP
ADAPTOR 75 90071 1 0-RING, 1.062" I.D.
23 86709 1 ADAPTOR, CARB. INLET 76 94637 1 OIL FILL TUBE
24 35586 2 HOSE CLAMP-BAND 1.50” 77 90072 1 0-RING .562” I.D.
25 86710 1 HOSE, CARB. INLET 78 86708 1 CARBURETOR SPACER
26 87993 1 . ELBOW, AIR CLNR. OUTLET 79 87478 1 GASKET, OIL FILTER
27 49815 2 HEX HD. CAPSCREW, ADAPTOR
M5-.8X 16MM 80 96627 1 BRACKET, STARTER SIDE
28 90536 1 GASKET, AIR CLEANER ENGINE MOUNT
OUTLET 81 90613 1 COVER, BREATHER CANAL
29 90021 1 BRACKET., AIR CLEANER 82 59635 1 #8 X 3/8” PLASTITE SCREW
SUPPORT 83 002-91297 1 STARTER WIRE
30 94665 1 HOUSING, FAN-UPPER 84 004-91297 1 TEMP. SWTCH GRND WIRE
31 93859 1 FAN, GENERATOR 85 59636 1 PLASTITE SCREW, #4 X .ЗГ
32 A5892 1 ASSY., MAGNET HOUSING 86 88905 1 EXTENSION SPRING
33 91437 1 HUB, MAGNET HOUS. ASSY. 87 92800 1 WRAPPER, ENGINE TOP
34 003-91297 1 TEMP. SWITCH WIRE 88 89062 1 HOSE, BREATHER
35 86673 1 BASE, AIR BOX 90 23762 2 WASHER,EXTERNAL
36 78601 1 ELEMENT, AIR FILTERV SHAKEPROOF-#10
37 86674 1 COVER, AIR BOX 91 22447 3 WASHER, INTERNAL
38 78609 2 BOLT, AIR CLNR. COVER SHAKEPROOF - .25"
39 66449C 4 HEX HD. CAPSCREW, 94 23484P 1 SNAP BUSHING
M6-1 X 80MM 96 23897 6 #10-M5 FLAT WASHER ^
40 49226 4 LOCKWASHER, M5 97 94090 1 SWITCH-THERM., OIL TEMP.
41 80934 1 RETAINING RING, STATOR 99 86675A 1 ADAPTOR, OIL FILTER
42 A5898 1 ASSEMBLY STATOR 100 77667 1 SWITCH, OIL PRESSURE
43 86692 1 ADAPTOR, STATOR 101 86714 1 SCREEN, OIL PICK-UP
44 74908 3 TAPTITE, M5-0.8X 10MM 102 52617 1 DRAIN PLUG,
45 86735 1 COVER, CHOKE MOUNT M12-1.75X20MM
46 47488 4 SCREW, 4-40 X. 188” 103 94643 1 GASKET, OIL DRAIN PLUG
47 22159 4 LOCKWASHER - #4 104 70728 2 SCREW, M3-0.5 X 5MM
48 31879 4 FLATWASHER - #4 105 43182 2 LOCKWASHER, М3
49 91306 1 SOLENOID, CHOKE 106 A1627 1 AIR CLEANER DECAL
50 36544 1 PIN, COTTER 3/32” X 1/2” 107 A8617 4 HEX HD. TAPTITE M6-1X25MM
51 89473 1 ASSY., BI-METAL & HEATER 108 86726 1 SKIRT, BAFFLE
52 86736 1 LINKAGE, CHOKE CONT. 109 56893 1 CRIMPTITE, 10-24X1/2”
53 45756 3 M6-1 X 10MM TAPTITE 110 A9257 1 SHIM,STARTER
54 83512 1 TAPTITE M8-1.25 X 15MM
— 37 —
