SECTION 4 - GENERAL MAINTENANCE & ADJUSTMENTS

4.1 CONTROLS AND FEATURES

WARNING: AVOID INJURY. Read and
understand the entire Safety section before
proceeding.

1. Seat

6. Mower Deck

2. Forward and Reverse Pedal

7. Parking Brake

3. Throttle Lever

8. Steering Wheel

4. PTO Switch

9. Discharge Chute

5. Ignition Switch

10.Mower Lift Lever

11 .Fuel Tank

Figure 4

4 - 9
