MODELS бЗОС, 634F & 634В
Hold Tines With Blunt End Toward You
t Used on Left side of tiller
^
Used on Right side of tiller
(A)
For Model 630C
(B)
For Model 634F
(G) For Model 634B
REF
NO.
PART NO.
DESCRIPTION
REF
NO.
PART NO.
DESCRIPTION
1
710-3005
Hex Hd. Screw, 3/8-16 x 1 -1/4, Grade 5
10
GW-9338
Hair Pin Cotter
2
GW-50049-01
Single Boto Tine - Right Handf
(A) (B) (C)
11
736-0169
Lock Washer, 3/8
(ВИО
3
712-3000
Hex Lock Nut, 3/8-16
—
GW-1901
Bolo Tine Replacement Set (Incl. eight
4
710-0347
HexHd. Screw, 3/8-16x1-3/4
right-hand tines, eight left-hand tines and
5
GW-50049-02
Single Bolo Tine - Left Handt
(A) (B) (C)
required hardware.
(A) (B) (C)
6
1916747
Tine Holder (BMC)
—
642-0029
Left Hand Tine Assembly^: (Incl. one tine
1915075
Tine Holder
(A)
holder and eight tines, assembled)
(B)
{C}
7
1917486
Wheel
&
Tire Ass’y — Left/Right Side(B)
642-0030
Right Hand Tine Assemblyf {Inch one tine
holder and eight tines, assembled) (B) (C)
1917487
Wheel
&
Tire Ass’y— Left/Right Side
(C)
____
642-0031
Left Hand Tine Assembly^ (Incl. one tine
GW-55095-01
Wheel
&
Tire Ass’y — Left Side Only
(A)
holder and eight tines, assembled)
(A)
8
GW-55095-02
Wheel S Tire Ass’y — Right Side Only
(A)
—
642-0032
Right Hand Tine Assemblyf (Incl. one tine
9
GW-9380
Clevis Pin, .312" X1-3/4"
holder and eight tines, assembled)
(A)
