Models 12214 and 12193
PARTS LIST
TRANSMISSION HOUSING, COVERS, SEALS, GASKETS AND PLUG
REF.
No.
PART
No.
DESCRIPTION
QTY.
REF.
No.
PART
No.
DESCRIPTION
QTY
1
9727
Plug, Transmission Oii Fili...............
1
10
1909374
Oil Seal, Tine Shaft...................... ... 2
2
1186328
Flange Screw, Grade 5,5/16-18x5/8.
8
11
55011-1
Gasket, Bearing Cap {.010" thick)....
... 1
5
1916641001
Front Cover, Transmission..............
1
55011-2
Gasket, Bearing Cap {.030" thick).... 1
5A
50074
Rear Cover, Transmission...............
1
12
1916111001
Rear Bearing Cap........................ ... 1
6
50032
Gasket, Housing Cover....................
2
13
1186331
Flange Screw, sh 6-18x1 ............. ... 2
7
9617
Oil Seal, Drive Shaft.......................
1
14
1100044
Flange Screw, 5/16-18 x 3/4........ ... 1
8
9621
Oil Seal, Wheel Shaft......................
2
15
1100242
Lockwasher, 5/16........................ ... 1
9
1916975001
Transmission Housing Assembly......
1
