Troy-Bilt 12214-5.5HP - Manual (Page 27)

Models 12214 and 12193
PARTS LIST
HANDLEBARS, CLUTCH CABLES AND HANDLEBAR MOUNTING HARDWARE
REF.
No.
PART
No. DESCRIPTION QTY.
REF.
No.
PART
No. DESCRIPTION QTY
1 1916996 Upper Handlebar (Inci. Refs. 2 & 28). . 1 16 1100044 HexHd.Screw, 5/16-18x3/4.......... .... 2
2 1916928 Decal, Forward Clutch Bail............. . 1 17 1902173001 Handlebar Support...................... .... 2
3 9854 Curved Hd. Screw, 5/16-18 x 1-1/2.... . 6 18 1110107 Hex Lock Nut, 5/16-18................. .... 2
4 1100806 Hex Hd. Screw, 1/4-20x1-1/4......... . 1 19 1902174001 Lower Handlebar......................... .... 1
5 55044 Bracket, Forward Clutch Cable........ . 1 20 9386 Klip Ring..................................... .... 1
6 1916106001 Bail, Forward Clutch...................... . 1 21 9856 Clevis Pin.................................... .... 1
7 9855 Screw, #10-24x2........................... . 1 22 9552 Hex Hd. Screw, 1/4-20 x 1/2,
8 1916712 Spring, Forward Clutch.................. . 1 Self-Tapping.......................... .... 6
9 1100242 Lockwasher, 5/16.......................... . 6 23 1901273001 Panel......................................... .... 1
10 1186230 Hex Nut, 5/16-18.......................... . 6 24 1917559 Decal, Logo................................ .... 1
11 9811 Hex Lock Nut, 1/4-20..................... . 1 25 1916674001 Bracket, Reverse Clutch Cable..... .... 1
12 55048 Cable /Assembly, Forward Clutch..... 1 26 1916719 Cable Assembly, Reverse Clutch.. .... 1
13 1100068 HexHd. Screw, 3/8-16x3/4............. . 2 27 1186227 Hex Nut, #10-24........................ .... 1
14 9837 Hex Lock Nut. 3/8-16..................... . 2 28 1916929 Decal, Reverse Drive Control....... .... 1
15 1107383 Flat Washer, 3/8........................... . 2 29 1735531 Cable Tie................................... .... 2
