Ariens Sno-Thros 924000 Series - Manual (Page 12)

TRACTOR PARTS FOR MODELS
924046, 924048, 924050 & 924052
PIECES DU TRACTEUR DES MODELES
N o de N0 DE CODE
REF. piece D'INV
»re CT«»., DESCRIPTION
REF. PART STOCK
NO. NO. CODE
QUANTITÉ
Ш
eoo»
1 II
(N СМеМ
OB 99 Ç
NO. RÉQ'D
S a a
OO O
0999 99
N o de N o DE CODE
REF. PIECE D'INV.
REF. PART STOCK DESCRIPTION
NO. NO. CODE
QUANTITÉ NO, REQ'D
CO 00 09 о ^ H
« s 'A £ ^
о о о о о о
^ ^ ^ ЧГ
«N ГМ <М «N esj
09 09 09 09 09 09
1 070009 M FLANGE WHIZL0CK SCREW 8 8 8 8 58 067002 F COTTER PIN 3/32x1 2 2 2 2
2 060012 M SETSCREW 1 1 1 1 59 024069 0 FORK PIVOT ROD 1 1 1 1
3 063003 M LOCKWASHER 5 5 5 5 60 024272 0 CLUTCH FORK 1 1 1 1
4 024074 M PINION CHAIN • 1 1 61 083094 S SPRING 1 1 1 1
5 024073 M IDLERCHAIN - 1 1 62 624027
s
SPRING ASSEMBLY 1 1 1 1
012078 M IDLER CHAIN 1 1 • 63 010542
s
ADAPTER SPACER . 1 1 1 1
6 065040 M LOCKNUT 2 2 2 64 065062 M LOCKNUT, NYLON 1 1 1 1 1
7 059028 M CAP SCREW y.-20x)4 2 2 - 2 65 054039 M BEARING, BALL 2 2 2 2 1
8 024236 M BELT FINGER 1 1 1 66 022002
s
SPINDLE HOUSING 1 1 1 1 1
9 010142
s
BEARING FLANGE 2 • 67 024155
s
BEARING SPACER 1 1 1 1 1
9 024363
s
BEARING RETAINER ■ 2 2 68 022003
s
DRIVE SPINDLE HOUSING 1 1 1 1
10 054136 M BEARING BALL • 2 2 69 003034 M ROLLER 1 1 1 1
10 054093 M BEARING,RADIAL 2 - - 70 024076
s
SPINDLE 1 1 1 1
11 065056 M LOCKNUT 6 6 6 8 71 010546 M DRIVE PLATE 1 1 1 1
12 070058 F RIBBED NECK BOLT ■ - - ■ 8 72 024071 M DRIVE DISC SPACER 1 1 1 1
13 070015 F FLANGE WHIZLOCK SCREW 9 9 9 9 73 064123 F WASHER, 5/16x11/16x.065 1 1 1 1
14 024077 M SHAFTSUPPORT 4 4 4 4 74 059003 M CAPSCREW 5/16-18x1 1 1 1 1
15 070011 F RIBBED NECK BOLT 6 • 6 75 063018 M LOCKWASHER 3 3 3 3
16012023 S BEARING SUPPORT 2 • 78 065015 F NUT 4 4 4 4
17 055039 M FLANGED BUSHING 2 • - 77 010485 S STREET ELBOW 1 1
18 003017 M BEARING FLANGE 2 • 78 012222 M NIPPLE 1 1
19 024338 6 HEX SHAFT 1 1 79 025208 M CAP 1
19 024045 0 HEX SHAFT - 1 1 80 075040 0 BUTTON PLUG 1 1 1 1
20 066015 M KEY, WOOD RUFF 1/8x5/8 1 1 1 1
81 075050 M SNAP BUSHING 1 1 1 Г
21 010276
s
9 TOOTH SPROCKET 1 1 1 1
82 022161 0 SHORTING WIRE 1 1 1 1
22 025089
s
ROLLER 1 1 • 83 624022 0 CARRIER 1 1 1 1
23 064058 M WASHER .500/.505x1x.062 2 2 2 2 84 65086 M LOCKNUT 1 1 1 1
24 003085 S BEARING FLANGE 1 1 1 1 85 054093 M BEARING, RADIAL 1 1 1 1
25 054080 S BEARING, RADIAL 1 1 1 86 064071 M WASHER 1 1 1 1
26 065054 M LOCKNUT 1 1 1 1 87 057021 M SNAP RING' INTERNAL 1 1 1 1
27 065094 F LOCKNUT 4 4 4 4 88 024454
s
DISC HOB 1 1 1 1
28 024366 S SHAFTSUPPORT 1 1 89 003003 F FRICTION DISC 1 1 1 1
28 024339 S CLUTCH STOP 1 1 1 90 065077 M LOCKNUT 1 1 1 1
- 29 022063 M SPIN-DRIVE ZERK FITTING 2 2 2 91 024455
s
SPINDLE HUB 1 1 1 1
30 065018 F NUT - 2 2 92 059022 M CAP SCREW, 5/16-18x3/4 1 1 1 1
31 063014 M LOCKWASHER 2 2 93 024228 0 CLUTCH ENGAGEMENT YOKE 1 1 1 1
32 064093 F WASHER .380/.385x3/16x.062 2 2 94 024086
s
SPACER 1 1 1 1
33 055040 M BUSHING 2 2 95 024227
s
ADAPTER 1 1 1 1
34 024364 S REDUCTION SHAFT • 1 1 96 022135
s
ROD ADAPTER 1 1 1 1
35 024367 S PINION SHAFT 1 1 1 1 97 524002 0 PINION 8i SPROCKET 1 1
_
36 064036 M WASHER .В5/.в35х.005х.062 5 5 5 5 97 524032 0 PINION & SPROCKET
_
1 1
37 058009 F ROLL PIN 1 1 1 1 98 624072 0 SPROCKET ASSEMBLY
_
1 1
38 055026 M FLANGED BUSHING 4 4 4 4 99 024081
s
CARRIER SHAFT 1 1 1
39 058029 F ROLL PIN 3 3 3 3 100 066006 M WOODRUFF KEY 1 1 1 1
40 063025 F LOCKWASHER 1 1 1 101 055057 M BUSHING 1 1
41 610938 0 AXLE ASSEMBLY L.H. 1 101 055029 M BUSHING _ 2
41 624074 0 AXLE LH. - 1 102 024141 M BEARING FLANGE 1 1 1 1
41 624083 0 AXLE ASSEMBLY L.H. 1 103 055126 M SPACER 1 1 1 1
42 055029 M SLEEVE BUSHING 2 1 1 104 013136 M ZERK FITTING 1 1 1 1
43 010374
s
PIN 1 1 1 105 073049 M PULLY 1 1 1 1
44 083007
s
SPRING 1 1 1
45 058042 M GROOVE PIN 1 1 1
46 010372 F LOCKNUT, HOB 1 1 1
47 058032 F ROLL PIN 3/32x1 1 1 1
48 010375 S KNOB 1 1 1
49 067001 F COTTER PIN 3 3 3 3
50 024233 S SHIFT LINK 2 2 2 2
51 024232 S LEVER SHIFT ARM 1 1 1 1
52 012151 S CLEVIS PIN 2 2 2 2
53 059039 M CAPSCREW 5/16-18x14 4 4 4 4
54 059136 M CAPSCREW 5/16-18x3 1 1 1 1
55 024231 0 BRACKET SHIFT LEVER 1 1 1 1
56 024115
s
SPACER 1 1 1 1
57 065042 F LOCKNUT 3 3 3 3
SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY -13-
CODE SUGGÈRE D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S - SLOW (lent)
M — MEDIUM (moyen) O — Commande du client seulement
