NO. NOTE PART NO. .P.^.T 2 ESC RIP T I O
.... i........................W304............ y ’COORD’iNATE ...............
2 387081 FELT A
3 387405 SCREW
4 387900 Y COORDINATE DRIVE PLATE
5 387363 Y AXIS DETECTING SWITCH (ASM. )
REF
Qty
. . T..
1
2
1
1
6 387302 NUT 1
7 283485 SCREW 1
8 387902 Y AXIS BELT FIXING PLATE 1
9 387898 Y AXIS INTERMEDIATE PULLEY BRACKET (ASM. ) 1
10 385352 WASHER 1
11 387897 Y AXIS INTERMEDIATE PULLEY 1
12 387314 PULLEY FLANGE 1
13 283460 E RING 1
14 387135 SCREW 1
15 387899 Y AXIS FOLLOWER GEAR BRACKET (ASM. ) 1
16 385352 WASHER 1
17 387890 Y AXIS FOLLOWER GEAR 1
18 283460 E RING 1
19 387135 SCREW 1
20 387901 Y COORDINATE DRIVE BELT B 1
21 387092 Y COORDINATE DRIVE BELT A 1
22 283470 SCREW 3
23 387311 Y COORDINATE PULLEY (ASM. ) 1
24 387135 SCREW 1
25 387904 FRAME HOLDER (ASM. ) 1
26 387896 Y COORDINATE BELT HOLDER 1
27 386493 SCREW 1
28 387906 FRME FIXING SPRING 1
29 283491 SCREW 2
30 387098 EMBROIDERY FRAME CLAMP SPRING 1
31 283469 SCREW 1
32 387099 EMBROIDERY FRAME POSITIONING COLLAR 1
33 387133 SCREW 1
34 387905 EMBROIDERY FRAME DETECTING SWITCH GUIDE 1
35 283469 SCREW 1
36 387364 EMBROIDERY FRAME DETECTING SWITCH BOARD (ASM. ) 1
37 387391 SCREW 4
38 387006 BAND (SMALL) 4
39 387100 EMBROIDERY FRAME DETECTING LEAD COVER 1
40 386508 SCREW 1
41 387910 FRAME HOLDER COVER 1
42 283522 SCREW 1
