REF
NO. NOTE PART NO. PART D E S C R I P T I O N Q t y
1 388321 TOP COVER (ASM. ) 1
2 387921 EMBROIDERING UNIT HANDLING CAUTION SEAL (1)
3 387916 DUST-PROOF SEAT A (2)
4 387909 SIDE COVER (ASM. ) 1
5 387917 DUST-PROOF SHEET B (2)
6 386520 SCREW 2
7 283451 NUT 1
8 387154 SCREW 2
9 387908 BOTTOM COVER 1
10 387440 RUBBER SEAT 2
11 387918 CHANGE-OVER LEVER (ASM. ) 1
12 386530 WASHER 1
13 283522 SCREW 1
14 387920 CHANGE-OVER KNOB 1
15 387919 CHANGE-OVER LEVER HOOK 1
16 386420 HOOK SHAFT 1
17 386421 HOOK SPRING 1
18 283522 SCREW 2
19 387923 TRIGGER PIN 1
20 387924 TRIGGER PIN SPRING 1
21 283460 E RING 1
22 283528 WASHER 1
23 387925 TRIGGER LIMIT PLATE 1
24 387926 FULCRUM SHAFT 1
25 387927 RETURN SPRING 1
26 387389 E RING 2
27 387299 MODE CHANGE-OVER CONTACT 1
28 388324 MODE CHANGE-OVER SW PLATE FIXING PLATE 1
29 387929 MODE CHANGE-OVER SWITCH (ASM. ) 1
30 283485 SCREW 1
31 387302 NUT 1
32 283522 SCREW 2
33 283335 START SWITCH LEAD TAPE 1
34 283322 CORD HOLDER 1
35 283522 SCREW 1
36 387362 CONNECTING SLIDER A (TOTAL ASM. ) 1
37 387911 CONNECTING SLIDER A (1)
38 387930 DRIVER CABLE (TOTAL ASM. ) (1)
39 387412 SCREW (2)
40 387006 BAND (SMALL) (1)
41 387928 SLIDER COVER 1
42 386528 SCREW 2
43 387418 WASHER 2
44 386528 SCREW 2
45 388323 CONNECTING SLIDER B 1
46 388230 LEVER SW LINK (ASM. ) 1
47 388231 LEVER SW LINK SPRING 1
48 386762 WASHER 1
49 283459 E RING 2
50 387913 SLIDER SPRING 2
51 283460 E RING 2
52 388322 SLIDER FULCRUM PLATE 1
53 387410 SCREW 2
54 387915 SLIDER WORKING PLATE (ASM. ) 1
55 387154 SCREW 5
56 388325 DE CONTACT 1
57 388326 DF CONTACT GUIDE 1
58 388327 DF FELT 1
59 388328 DF CONTACT SPRING 1
60 283522 SCREW 2
61 388329 EMBROIDERY UNIT REMOVING/INSTALLING DETECTION SW(ASM. ) 1
62 388344 WASHER 1
63 388345 SCREW 1
64 387006 BAND (SMALL) 1
- 4 0 -
