REF
NO. NOTE PART NO. PART D E S C R I P T I O N Q t y
1 388280 HOOK (TOTAL ASM. ) 1
2 387353 ROTATING HOOK (TOTAL ASM. ) (1)
3 * 388149 ROTATING HOOK (PARTIAL ASM. ) (1)
4 * 387395 SCREW (1)
5 * 387578 HOOK OF ROTATING HOOK (1)
6 * 387400 SCREW (1)
7 * 387579 TOP THREADING CUTTER FIXING BASE (1)
8 387338 TOP THREADING CUTTER (1)
9 * 387396 SCREW (1)
10 388150 HOOK SHAFT (ASM. ) (1)
11 387570 WASHER (UPPER) (1)
12 387575 ROTATING HOOK MAGNET (ASM. ) (1)
13 387580 SPRING (1)
14 385336 SCREW (1)
15 388281 BOBBIN CASE (TOTAL ASM. ) (1)
16 386230 NEEDLE PLATE PILE B (1)
17 385352 WASHER 1
18 388231 BOBBIN THREAD MECHANISM BASE (TOTAL ASM. ) 1
19 388154 BOBBIN THREAD MECHANISM BASE (ASM. ) (1)
20 * 387355 BOBBIN THREAD SUPPLY STM (ASM. ) (1)
21 * 387789 BOBBIN THREAD INTERMEDIATE GEAR (1)
22 * 387790 BOBBIN WINDER DRIVE PLATE RACK (1)
23 283460 E RING (2)
24 387791 BOBBIN WINDER DRIVE PLATE (1)
25 283460 E RING (2)
26 387792 SPRING (1)
27 * 387793 GEAR CONNECTING LINK STOPPER (1)
28 387794 SPRING (1)
29 283486 SCREW (1)
30 387795 GEAR CONNECTING LINK (ASM. ) (1)
31 * 387796 GEAR CONNECTING LINK PLATE SPRING (1)
32 283469 SCREW (1)
33 283459 E RING (1)
34 387797 NEEDLE THREAD CATCHING PLATE (1)
35 283486 SCREW (1)
36 387577 HOOK SHAFT BASE (ASM. ) (1)
37 387408 SCREW (1)
38 387602 GEAR COVER FIXING SHAFT A (2)
39 387799 THREAD HOLDING PLATE (B) (1)
40 387800 THREAD HOLDING PLATE SHAFT A (1)
41 387801 THREAD HOLDING PLATE SHAFT B (1)
42 387798 THREAD HOLDING PLATE C (1)
43 387406 SCREW (2)
44 387357 THREAD HOLDING PLATE (TOTAL ASM. ) (1)
45 * 387802 THREAD HOLDING PLATE (ASM. ) (1)
46 * 387413 WASHER (1)
47 * 387803 BOBBIN WINDER TENSION PLATE (ASM. ) (1)
48 * 387804 SPRING (1)
49 * 387386 E RING (1)
50 * 387805 THREAD HOLDING SPRING (1)
51 * 385335 SCREW (1)
52 * 387414 WASHER (1)
53 387406 SCREW (1)
54 387569 HOOK DRIVING SHAFT SUPPORT OF HOOK (1)
55 283491 SCREW (1)
56 * 387356 BOBBIN THREAD ORIGIN SENSOR BOARD (ASM. ) (1)
57 * 387808 THREAD HOLDING PLATE COVER SENSOR BOARD (1)
58 387714 LINK COVER (1)
59 387607 REMAINING AMOUNT SENSOR FIXING PLATE (1)
60 387604 FIXING PLATE (GIVE LIGHT) (1)
61 387606 REMAINING AMOUNT SENSOR BOARD (GIVE LIGHT) (ASM. ) 1 (1)
62 387400 SCREW (1)
63 283491 SCREW (1)
64 388151 SCREW (2)
65 283470 SCREW (1)
66 388153 HOOK DRIVING SHAFT SUPPORT A (1)
67 388152 HOOK DRIVING SHAFT SUPPORT A FITTING PLATE (1)
68 283491 SCREW (2)
69 283502 SCREW 1
70 283480 SCREW 4
71 283322 CORD HOLDER 1
72 387006 BAND (SMALL) 1
73 387006 BAND (SMALL) 1
- 2 4 -
