SINGER XL-6000 - Manual (Page 32)

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Q t y
1 387809 kne ; e lifter insert ( asm . ) 1
2 * 387823 KNEE lifter pad (1)
3 387814 washer
1
4 387810 KNEE LIFTER CONNECTING SHAFT (ASM. ) 1
5 387811 spring
1
6 283486 SCREW 1
7 387417 WASHER 1
8 387812 SPRING 1
9 387813 KNEE LIFTER LINK PLATE (TOTAL ASM. ) 1
10 283502 SCREW 2
11 387815 KNEE LIFTER LINK 1
12 387816 KNEE LIFTER LINK ARM A 1
13 387817 KNEE LIFTER LINK ARM B (ASM. ) 1
14 387818 FULCRUM SHAFT 1
15 387142 SCREW 1
16 283461 E RING 1
17 387422 WASHER 1
18 387820 SPRING 1
19 387819 SPRING HOOK 1
20 283502 SCREW 1
21 387821 KNEE LIFTER RELEASE PLATE (ASM. ) 1
22 387822 KNEE LIFTER RELEASE LINK (ASM. ) 1
23 283459 E RING 1
24 386118 ECCENTRIC COLLAR 1
25 386520 SCREW 2
26 283471 SCREW 1
- 2 8 -
