SINGER XL-6000 - Manual (Page 22)

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Q t y
1 384347 NEEDLE PLATE (ASM. ) 1
2 387426 NEEDLE PLATE (1)
3 387430 BOBBIN CASE COVER (1)
4 386230 NEEDLE PLATE PILE B (1)
5 386059 STOPPING PLATE (LEFT) (1)
6 386057 HOOK COVER SPRING (1)
7 387428 HOOK COVER SUPPORT PLATE (1)
8 387429 HOOK COVER OPEN/CLOSE BUTTON (1)
9 387431 HOOK COVER BUTTON SUPPORT (1)
10 386062 NEEDLE PLATE PILE A (1)
11 386505 SCREW (2)
12 283478 SCREW (1)
13 386505 SCREW (1)
14 385336 SCREW (1)
15 386229 NEEDLE PLATE RUBBER (1)
16 283355 BAND 2
17 387427 HOOK COVER (ASM. ) 1
18 387545 SCREW 2
19 388229 LATERAL FEED STM FIXING PLATE (TOTAL ASM. ) 1
20 * 387553 THREAD TRIMMING GEAR (1)
21 387556 THREAD RELEASE ARM (1)
22 283460 E RING (1)
23 387555 KNIFE DISENGAGING CONTACT (1)
24 283459 E RING (1)
25 * 387348 LATERAL FEED STM (1)
26 387561 RELAY LEAD WIRE (ASM. ) (1)
27 283491 SCREW (2)
28 387874 MAIN SHAFT DETECTING BOARD (ASM. ) (1)
29 * 387549 LATERAL FEED STM GEAR (ASM. ) (1)
30 * 283506 SCREW (2)
31 * 283506 SCREW (1)
32 387558 GEAR PIN (1)
33 385349 WASHER A (2)
34 386762 WASHER B (1)
35 387560 SPRING WASHER (1)
36 387550 LATERAL FEEDLINK (ASM. ) (1)
37 385349 WASHER A (1)
38 283459 E RING (1)
39 387557 THREAD TRIMMING GEAR STOPPER (1)
40 387532 ORIGIN DETECTING RUBBER (1)
41 283491 SCREW (1)
42 387559 HOOK DRIVING SHAFT SUPPORT (1)
43 283470 SCREW (1)
44 387349 DRIVER CABLE (TOTAL ASM. ) (120V) (1)
45 388099 DRIVER CABLE (TOTAL ASM. ) (230V) (1)
46 283458 E RING (2)
47 * 387554 LATERAL FEED STM FIXING PLATE (ASM. ) (1)
48 387551 LATERAL FEED LINK SPRING (1)
49 386493 SCREW (1)
50 283322 CORD HOLDER 1
51 283502 SCREW 3
52 386520 SCREW 1
- 1 8 -
