3-6. Adjustments for Size of Bight.
• Adjust the size of the bight from 4.2mm (0.16")
to 6.0mm (0.23") according to the kind of
material.
• The standard bight size is 4.5mm (0.17")
• Open the side cover to adjust the bight size.
(1) If the cutting width is narrower than the bight
size, turn the bite width adjusting dial to the direc
tion of arrow. (To bigger number)
(2) If the cutting width is wider than the bight size,
turn the bite width adjusting dial to the direction of
the arrow, a smaller number)
The right figure shows that the size of the bite
between the left needle and the edge of the
material 4.5mm.
4----------- 1
cr
D
