Cooper Lighting 610 User Manual
610 series

610 SERIES
I n t e r i o r W a l l L u m i n a i r e
D i r e c t / I n d i r e c t
Tw o R i n g B o w l
w i t h a n A r m M o u n t
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog #
Type
Date
Project
Comments
Prepared by
610 Direct/Indirect Two Ring Luminous Bowl with an arm mount
bracket.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Aluminum arm and wall canopy.
Aluminum or cold rolled steel
rings with matte white acrylic
bowl.
F i n i s h
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Lacquered Satin
Chrome (SCL), Lacquered Satin
Nickel (SNL) or Custom Color
(CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
L a m p / S o cke t
Two (2) 26W (G24q-3) 4-pin quad
CFL lamps or two (2)100W A-19
lamps. CFL socket injection
molded plastic. INC socket fired
ceramic rated for 660W-250V.
Lamps furnished by others.
I n s t a l l a t i o n
Supplied with a mounting plate
for a standard 4" J-box or plaster
ring.
O p t i o n s
Dimming Ballast - Contact
factory for ballast options (DM),
Top Louver - Contact Factory,
Hand Painted Faux Alabaster
Bowl (FB), Remote Emergency
Battery - Supplied by others
(REM), Damp Locations (DL): All
Painted finishes, Lacquered Satin
Chrome (SCL), Lacquered Satin
Nickel (SNL), finishes only.
Energy Star Rating - Consult
factory. MRI Applications (INC
only) - Contact Factory.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
D E S C R I P T I O N
ADS042655
2008-09-12 11:05:45
MAGNETIC
RESONANCE
IMAGING (MRI)
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Sample Number: 610-CFL/2/26-277V-PCP
Finish
Standard
NA Natural Aluminum
=
Premium
CC Custom Color
=
MW Matte White
=
PB Polished Brass
=
PC Polished Chrome
=
PCP Polished Copper
=
SAL Lacquered
Satin Aluminum
=
SB Satin Brass
=
SC Satin Chrome
=
SCL Lacquered
Satin Chrome
=
SCP Satin Copper
=
Options
DL Damp Location
=
DM CFL Dimming
Ballast
2
=
REM Remote
Emergency
Battery
3
=
FB Hand Painted
Faux Alabaster Bowl
=
Voltage
120V
277V
1
347V
1
Series
610 Two Ring Bowl
w/ Arm Mount
=
Lamp
CFL/2/26
INC/2/100
1 Available with CFL only.
Notes:
2 Consult the factory for available options.
3 Supplied by others.
O R D E R I N G I N F O R M AT I O N
