MÁME OF EACH PART
28 B
/21 Í2ÍI \|3
\|8
\t?
1. Built-in darner (Regulating plate)
2. Built-in darner (Release lever)
3. Thread take-up lever
4. Arm thread guide
5. Bobbin winder thread guide
6. 6’. Spool pin
7. Bobbin winder spindle
8. Bobbin winder stop latch
9. Balance wheel
10. Graduation plate
11. Feed regulating lever stop screw
12. Feed regulating lever
13. Light switch
14. Thread guide
1 5. Drop feed indicator
16. Drop feed dial
17. Calibrated upper thread tension régulât
18. Thread take-up spring
19. Needle bar
20. Needle
21. Presser foot
22. Shuttle race
23 Slide plate
24. Presser bar
25. Presser foot lifter
26. Oiling button
27. Plastic viewer
