4. TO REPLACE AND REMOVE THE BOBBIN CASE

(1) Raise the presser bar (24) by lifting the presser bar lifter (25)

(2) Raise the needle bar (19) to its highest point, by turning the Balance Wheel

toward you.

(3)

Open the hinged plate (23) (Fig. 8).

■

(4)

After threading the bobbin case, hold its latch between the thumb and torefinger

of left hand, with its position

finger opposite the notch at the

top of the shuttle race, replace

it on the center stud of the

shuttle (Fig. 9)

(5)

Then release the latch and press

the bobbin case back until the

latch catches the groove near

the end of the stud.

(6)

Allow the end of the thread to

hang free.

Fig. 8

(7)

Close the plate.

To remove fFig. 8, 9)

Do (1) (2) (3) as above.

(4)

Hold the bobbin cose latch between

the thumb and forefinger of lefi hand

and take out the bobbin cose from the

machine.

Fig, 9
