Turn Balance Wheel
towards you until the
take-up lever is raised to
its highest point. Place
spool of thread on the
spool pin of the machine
arm ; pass thread over
and through the thread
guide Fig. 9 (A) at the
top corner of the face­
plate, down and over the
back to front between
the tension-disc Fig. 9
(Bj up to thread guard
Fig. 9 (C), down into
the hook of take-up spr­
ing Fig. 9 (D) and over
back to front through
hole in the end of the
thread take-up-lever Fig.
9 (E) down into the
eyelet of the face-plate,
Fig. 9 (F) into the lower }
wire-thread guide, Fig. 9
(G) Ihen from left to
right through eye of the
needle Fig. 9 (H j .
Draw about 2" of thread
through the eye of the
needle with which to commence sewing. Hold needle
thread in your left hand, turn balance wheal towards
you until needle moves up and down and up again to
its highest point, catching the bobbin thread, which will
be brought up that way through the hole in the thread
plate.
FIGURE 9
