CLEANING AND OiUNG
THE SHUTTLE AREA

iti

The stitch forming mechanism occasional

ly becomes clogged with- loose threads
and lint. This win interfere with the
efficient

operation

the

machine.

Cleaning and removal of the lint will
safeguard the performance.

To remove the shuttle assembly, proceed
as follovvs;

Turn hand wheel until the needle

reaches its highest position. Tilt head
back on its binges.

Remove bobbin case (A).

Turn the two shuttle race cover clamps

(f) outward and remove the shuttle

race cover (C) and the shuttle body
(E) and the lint cleaner (D).
Clean the shuttle race, the shuttle, and
shuttle race cover by removing all
threads, lint, etc.

'-t'iiin tite cleaning has been completed, proceed as follows to replace the shut

fie assembly.

anuu

?, Turn hand wheel until the needle reaches its highest position

T Place lint cleaner (Dl to shuttle driver and shuttle body (E) in race (hi

j sgaifWi shuttle driver and adjust into position,

p Repiaoe shuttle mce cover (C). fitting pin at lower edge into notch and lock

w,rn snuTue race cover damps, {fj, making certain the damps have

j be-

snapped securely

into position,

camps nave

A Put tXiiibin (8) into bobbin case (A).
