FEATURES AND PARTS
(Front View)
1. Spool Pins
2. Stitch Width Lever
1
3. Zigzag Stop Knobs
4. Hand Wheel
5. Wheel Clutch
6
. Bobbin Winder
7. Stitch Length Dial
8
. Reverse Push Button
9. Bobbin Winding Tension
10. Drop Feed Knob
11
. Cover Plate
12. Needle Plate-Seam Guide
13. Presser Foot
14. Needle Clamp and Screw
15. Attachment and Foot Thumb Screw
16. Needle Bar Thread Guide
17. Thread Guides
S f
T"
.... ~
18. Tension Regulator
19. Light Switch
20. Take-up Lever
"7 S'
21. Pressure Release-Darner
22..Arm Thread Guide
23. Cam Cover Chamber
