Page 59

Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

l7aZe™;trsrj7oVaTw;„'“""^H^"‘‘

wnicn

used for a few hours a day needs to

cleaned and oiled once a month.

Do not tamper with parts while cleaning or oiling.

* Be sure to unplug the machine while cleaning or oiling.

Feed dog

or other many troublet'^'^fheValways ^eL^irbe clean.'"’'’'“'"^' movement of the feed dog

(1) Set the needle in the highest position by

turning the handwheel toward you.

(2) Remove the needle, and the foot.

(3) Remove the needle plate, loosening the

screws with the large screwdriver.

(4) Brush off all the lint with the attached

cleaning brush.

Clean especially the upper part of the feed

dog and between the teeth.

Rotary hook

Dust or lint in the rotary hook cause the slow

so it always needs to be clean.

running of the machine or irregular stitches

(1) Open the shuttle cover and remove the

bobbin case.

(2) Brush off all the lint with the attached

cleaning brush.

»When the thread is rooted in the hook groove,

turn the handwheel away from you and take
out the thread.
