1 9
To Clean and Oil Shuttle--Lift and Tip Machine Backward
Occasionally the shuttle assembly gets clogged with lint, loose
threads or fabric dressings. Running machine threaded without
fabric under presser foot can also clog and tightly jam the
shuttle. Cleaning this assembly is simple. Cabinet or portable
hinges will hold machine at an angle. Underneath machine at
its left end you will see the assembly pictured here.
With
needle
at
its
TOPMOST
position--remove
Bobbin
Case
(Page 8). Push top end of BOTH cl
2
Lmps (B) outward--premitt-
ing removal of shuttle race covering (C) and shuttle (D)--hold
ing latter by its center pin. Thoroughly clean and polish ring
(C) and shuttle (D)--ALSO the shuttle race, the cavity IN THE
MACHINE where shuttle functions. If any scraping is necessary
be sure to cloth-cover the screw driver blade.
Before re-assembly put one drop of oil on a finger-tip and run
shnttle ( D ) . Holding shuttle (D) by its center pin and its hedi'
in and wiggle it slightly until you feel it fitting firmly against
stay put.
it aronnd the outer edge of
moon body toward you, push
shuttle driver, where it will
Then replace race cover ring (C)--fitting pin in its LOWER edge into notch. Push
both clamps (B) inward xintil they snap onto their holding pins. Last insert Bobbin Case (Page
8) and your machine should be ready for sewing.
To Replace The Motor Beit
Remove
circular
clutch
nut
from
wheel
by
turning
it
COUNTER-CLOCKWISE
after
removing
screw
( S ) .
Pull
wheel CAREFULLY away from machine ONLY FAR EN
OUGH
to
expose
its
grooved
belt
pulley.
Then
change
belts--the new for the old. If the large washer which must
fit between wheel and clutch nut has fallen o f f - - B E SURE to
replace it with its protruding lips OUTWARD--away from
wheel. Replace and tighten clutch nut and screw ( S ) .
