SLOT
Installing Filled Bobbin and Threading The Bobbin Case
Hold bobbin case with, slot in its edge up
(left). Hold bobbin with, fingers of other hand
so that end of thread points in CLOCKWISE
direction. Insert bobbin in case eind pull thread
into case edge slot (RIGHT). Then continue
pulling thread under tension spring and into
fork-shaped opening of spring (RIGHT), until
about three inches of thread protrudes.
SLOT
Put Bobbin Case Back In Machine By Reversing Procedure Page 8
T E N S I O N S M I N O
The Last Step Before Sewing
loosely in left and turn machine wheel
COUNTER-CLOCKWISE
until
needle
goes down and comes back up. The
needle thread you hold will be looped
by bobbin thread from below. Pull loop out straight anH place
BOTH threads under presser foot slot. Continue pulling them
toward back of machine forthree to four inches.
Finish Every Sowing Step The Right Way -
At
end
of
each
sewing
operation
turn
machine
wheel
COUNTER - CLOCKWISE by hand until Take-Up Lever and
Needle are at highest position. Rciise Presser Foot and draw
fabric toward back and sHghtly left, keeping threads UNDER
presser foot. Clip threads with sharp scissors or by raising
them over top of Machine Thread Cutter just above the
presser foot. Then pull down to cut threads using both
hands to avoid bending needle. Leave ends of both cut
threads under presser foot.
