AIR DIRECTION
The air direciion can be adjusted up, down,
left or right. The outside tabs adjust the air up
or down. The center levers direct the air left or
right.
Air Directional Louvers
6-way Louvers
The 6-way louvers permit upward or straight out air flow and
airflowdirectionfromsidetoslde.Thlstypeoflouverisfound
only on the side air discharge models. The side to side
adjustment of air flow direction is achieved by moving the
handle to either the left or right.
