gettirig to know your belt and disc sander
WARNING: TO AVOID INJURY FROM ACCI­
DENTAL START, TURN SWITCH “OFF” AND
REMOVE PLUG FROM POWER SOURCE OUT­
LET BEFORE MAKING ANY ADJUSTMENTS.
SANDING
PLATE
BACKSTOP
LOCK
BOLT
1
BACKSTOP
SANDING
BELT
SANDING
DISC
2
BELT
TABLE
lOCKINC
BOLTS
BELT
TABLE
WORKTABLE
ASSEMBLY
TABLE
SUPPORT
ROD
PULLEY
COVER gQLj
TABLE
STOP
9
ON-OFF
SWITCH
MOUNTING
HOLES
8
AUXILIARY
MOUNTING
HOLE
(WORKTABLE)
5
6 TABLE
TABLE ASSEMBLY
SCREW
KNOB
1. Backstop .. . Supports the workpiece on the
sanding belt.
2. Beit Table Locking Bolts . . . Loosening bolts
allows belt table to be raised to the vertical
position.
6
.
Table Assembly Lock Screw . . . Locks the
table assembly onto the table support rod.
Table Lock Knob . .. Loosening knob allows
the worktable to be tilted for bevel sanding
(Scale on table trunnion).
3. Tracking Knob . . . Turning knob clockwise
causes sanding belt to move towards the
disc;
turning knob counterciockwise causes
sanding belt to move away from the disc.
4. Tension Knob ... Sliding knob to the right re­
leases the sanding belt tension; sliding knob
to the left applies belt tension.
7. Toggle Bolt................. Locks the rod into the base.
8. Auxiliary Mounting Hole . . . Allows table
assembly to be mounted for end sanding on
the belt side.
13
