ACCESSORIES AND ATTACHMENTS

These accessories and attachments were available through most Sears retail outlets and service centers when the tractor was purchased

Most Sears stores can order these items for you when you provide the model number of your tractor.

ENGINE

MAINTENANCE

SPARK PLUG

GAS CAN

ENGINE OIL

FUEL STABILIZER

AIR FILTER I

Д

0

PERFORMANCE

Sears offers a wide variety of attachments that fit your tractor. Many of these are listed below with brief explanations of how they can help
you This list was current at the time of publication; however, it may change In future years - more attachments may be added, changes
may be made in these attachments, or some may no longer be available or fit your model Contact your nearest bears store tor tne
accessories and attachments that are available for your tractor-

Most of those attachments do not require additional hitches or conversion kits {those that do are indicated) and are designed for easy

attaching and detaching

AERATOR promotes deep root growth fora healthy lawn. Tapered
2 S-inch steel spikes mounted on 10-inch diameter discs puncture
holes in soil at dose intervals to let moisture soak in Steel weight tray
tor increased penetration

BuypER protects front end of tractor from damage

CARTS make hauling easy. Variety of sizes avaiiabie, pius accesso­
ries such as side panel Wts, tool caddy, cart cover, protective mat and
doily.
CORING AERATOR lakes small plugs out of soil to allow moisture
and nutrients to reach grass roots 36-Inch swath. 24 hardened steel
coring tips 150 ib capacity weight tray,

DISC HARROW has 2 gangs of 4 steel blades that angle from 10 to
20 degrees, 40 inches wide Can hook 2 units in tandem. (Requires
sieeve hitch.)

DOZER BLADE removes snow; grades dirt, sand and gravel. 48
inches wide,

17

inches high, clears 44-tnch path when angled Master

lift control lever for operator ease, Spring trip for snow removal on
uneven pavement; built-in float for biade to follow ground contour.
Reversible, replaceable scraper bar (Use with tire chains and wheel
weights and/or rear drawbar weight)

EASY OIL DRAIN VALVE makes oil changes easier, faster

FRONT NOSE ROLLER canters In front of mower deck to reduce
chances of "scalping" on uneven terrain,

GANG HITCH iets you tow 2 or 3 pull-behind attachments at
once, such as sweepers, delhatchers, aerators (not lor use with
rollers, carts or other heavy attachments).

MULCH RAKE/DETHATCHER

loosens soil and flips thatch and

matted ieaves to lawn surface for easy pickup. Twenty spring tine
teeth Useful to prepare bare areas for seeding- Avaiiabie for front or
rear mounting.

HIGH PERFORMANCE REEL-ACTION SPRING

TINE DETHATCHER

covers 36-Inch wide pathandtosses thatch into

large hopper Mounts behind tractor

PLOW turns soil 6 inches deep, cuts 10-inch furrow Crank adjust­
ment controls depth, 3-posltioh yoke sets width Heavy steel landside
for straight furrowing (Requires sleeve hitch )

RAMP TOPS AND FEET let you load and unload tractor from a
pickup truck Use wish 2x8 or 2x10 lumber

REAR GRADER BLADE is 42 inches wide and operated from driveds
seat Reversible steel blade can be angled at 30 degrees for grading
Reverses for pushing snow backwards (Requires sleeve hitch )

ROLLER

for smoother lawn surface, 36-inch wide. 18-mch diameter

water-tight drum holds up to 390 lbs of weight. Rounded edges
prevent harm to turf Adjustable scraper automaticaiiy cleans drum.

SLEEVE CULTIVATOR is 43 inches wide. Prepares ground for
seeding, helps weed control. Steel frame holds 5 adjustable sweeps.
Adjusts vertically, horizontally (Requires sleeve hitch ) Optional
accessory: steel furrow opener for wider openings for potatoes,
corn, and other deep-seeded crops

SLEEVE HtTCH for use with master lift system Single pin couples/

uncouples,

SNOVrrHROWER has 42-inch swath Drum-type auger handles

powdery and wet/heavy snow. Mounts easily with simple pin arrange­
ment. Discharge chute adjusts from tractor seat, 6-Inch diameter
spout discharges snow 10 to 50 feet. Lift controlied at tractor seat.
(Use with chains and wheel weights and/or rear drawbar weight )

SPRAYERS use 12-voit DC electric motorthat connects to the tractor
battery or other 12-volt source Sndudes booms for automatic
spraying and hand held wand for spot spraying Wand has adjustable
spray pattern. For applying herbicides, insecticides, fungictcies and

liquid fertilizers

SPREADER/SEEDERS make seeding, fertilizing, and weed killing
easy Broadcast spreaders are also useful for granular de-icers and
sand

SWEEPERS let you collect grass clippings and leaves

TILLER has 8 hp engine to prepare seed beds, cultivate, and compost

garden residue Chain-drive transmission. Six 11 -inch diameter one
piece heat-treated steel tines. Tills 30-Inch path (Requires sleeve
hitch ) Or use 5 hp low-behlnd TILLER with 36-inch swath to prepare
seed beds, cultivate and compost garden residue. Tiller has its own
built-in lift and depth control system and does NOT require a sleeve
hitch Fits any lawn, yard or garden tractor Simply hook up to the
tractor drawbar and got Optional accessories for5 hp tiller convert
unit for dethatching, aerating, hilling , without tools

TtRE CHAINS are heavy duty; closely spaced extra-large cross links
give smooth ride, outstanding traction,
TRACTOR CAB has heavy duty vinyl fabric over tubular steel frame,

ABS plastic top; clear plastic windshield offers 360 degree visibility.
Hinged metal doors with catch, Keeps operator warm and dry

Remove vinyl sides and windshields for use as sun protector in

summer.

Optional

accessories

include:

tinted/tempered

solid

safety glass windshleid with hand operated wiper; 12-volt amber

caution light for mounting on cab top

VACS for powerful collection of heavy grass dippings and leaves
Optional wand attachment to pick up debris in hard-to-reach places
VAC/CHIPPER includes a chspper-shrsdder,

WEIGHT BRACKET fordrawbarforsnow removal applications, Can
be mounted on front of tractor for plowing applications Uses (1)55
Ib weight.
WHEEL WEIGHTS for rear wheels provide needed traction for snow

removal or dozing heavy materiais
