BRIGGS AND STRATTON S H.P. ENGINE MODEL NO. 133402-0011-01
Repair Parts
REF.
NO.
PART
NO.
DESCRIPTION
54
284
300
613
832
864
883
94705
94620
494562
94729
494903
494904
*272309
ScreW'Hex.Head
Screw-Hex. Hd.
Muffler-Exhaust
Screw-Sem
Guard-Muffler
Flange-Muffler
Gasket-Exhaust
REF.
NO.
PART
NO.
DESCRIPTION
182
224709
Bracket-Fuel Tank
184
93559
Screw-Hex. Hd.
185
94010
Nut-Hex.
187
393815
Line-Fuel (11" Long. Cut to Suit)
187A
495218
Pipe-Fuel (Molded)
188
94357
Screw-Hex. Head
429
281190
Cover-Spark Plug
601
93053
Clamp-Fuel Pipe (Green)
Note: 93807 Clamp-Fuel Pipe
(Black)
957
493988
Cap-Fuel Tank
958
494539
Valve Ass’y.-Fuel Shut-Off
972
495345
Tank Ass’y.'Fuel
•Included in Gasket Set—Part No. 495661.
^188
Assemblies include ali parts shown in frames.
25
