SEARS CRAFTSMAN 5 H.P. LOG SPLITTER MODEL NO. 247.346250
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1 712-0359 Slotted Nut 3/4-16 Thd. 46 715-0116 Roll Pin
2 714-0162 Cotter pin 5/32“ Dia. 47 727-0311 Hitch Coupler
3 734-0873 Hub Cap 49 736-0116 FI-Wash. .635“ I.D. X .93" O.D.
4 734-1016 Wheel Ass'y. Comp. 50 736-0169 L-Wash. 3/8" I.D.*
734-0872 Tire Only 51 736-0185 FI-Wash. .406" I.D. X .75" O.D.
734-1017 Rim Only 52 750-0497 Spacer .44" Lg.
734-0255 Air Valve Only 53 781-0162 Jack Stand
5 736-0351 FI-Wash. .76" I.D. x 1.5” O.D. 54 781-0399 Tongue Tube
6 741-3028 Bearing Cone 55 781-0370A Locking Rod
7 736-0921 L-Wash. 1/2" I.D.* 56 781-0398 Beam Support Ass’y.
8 737-0192 90° Solid Male Adaptor 57 723-0405 Filter Element
9 737-0238 Pipe Nipple 1/2 NPT 58 723-0406 Filter Head
10 741-3029 Bearing Cup 60 727-0443 Return Hose 3/4* I.D. x 44" Lg.
11 737-0264 90° Male Adapter 61 781-0538 Hose Guard
12 736-0192 FI-Wash. .531" I.D. X. 94" O.D. 62 681-0014 Vertical Beam Ass’y-
13 710-0514 Hex Cap Scr. 3/8-16 x1"Lg. 66 714-0470 Cotter Pin 1/8" Dia.
15 710-1018 Hex Bolt 1/2-20 X 2.75" Lg. 68 738-0805 Hinge Pin 1/2 x 4.8" Lg.
(Grade 8) 73 710-0117 Hex Bolt 5/16-24 X 1" Lg.
16 710-1032 Hex Bolt 3/8-24 X 1.5" Lg. 74 710-0237 Hex Bolt 5/16-24 X .62" Lg.
17 712-0239 Hex L-Nut 1/2-20 Thd. 75 710-0363 Hex Bolt 5/16-24 x 4" Lg.
19 712-3001 Hex Jam Nut 3/8-24 Thd. 76 712-0123 Hex Nut 5/16-24 Thd.
(Grade 5) 77 714-0122 Sq.-Key3/16"x.75"
21 732-0583 Comp. Spring 4" Lg. 78 717-0891 Flexible Coupling
23 781-0323B Wedge Ass’y- 79 718-0249 Gear Pump
24 781-0537 Back Plate 80 719-0278 Coupling Shield
25 781-0350A Fixed Side Gib 81 726-0132 Hose Clamp 5/8"
26 781-0351 Adjustable Gib 82 727-0451 Suction Hose
27 781-0352A Adjustable Gib Shim 83 727-0324 High Pressure Hydraulic Hose 48’
28 781-0356 Floating Gib Plate 84 736-0119 L-Wash. 5/16" I.D.*
29 714-0203 External Cotter Pin 85 781-0097 Rear Coupling Support Brkt.
30 715-0216 Cylinder Mounting Pin 86 781-0098 Front Coupling Support Brkt.
31 718-0246 Hydraulic Cylinder 87 710-0157 Hex Bolt 5/16-24 X. 75” Lg.
32 717-0899 Control Valve 88 710-0409 Hex Bolt 5/16-24 X 1.75" Lg.
33 727-0323 Metal Pressure Tube 89 133402-0011-01 Engine—B&S 133402-0011 -01
34 781-0526 Hose Guard 90 736-0159 FI-Wash. .344" I.D. x .875" O.D.
35 737-0153 Return Elbow 91 737-0236 L-Vent Pipe Plug
36 737-0279 Adapter 92 735-0639 Spark Plug Boot
37 737-0235 3/4“ Hose Barb. 93 781-0556 Fender
38 726-0174 Hose Clamp 95 681-0011 Frame Weldment
39 710-0521 Hex Bolt 3/8-16 X 3" Lg. 96 720-0235 Grip
(Grade 8) 97 747-0583 Control Handle
40 710-0411 Hex Bolt 3/8-16 X 4" Lg. 98 732-0194 Spring Pin
41 710-0944 Hex Bolt 3/8-16 X 4.25“ Lg. 99 781-0525 Dislodger
(Grade 5) 102 750-0750 Spacer 1/2" I.D. x .86" Lg,
42 711-0813 Clevis Pin 5/16 X 2.5" Lg. 103 721-0168 Bearing Seal Only
43 712-0375 Hex L-Nut 3/8-16 Thd. 104 736-0262 FI-Wash. 3/8" I.D. X .87" O.D.
44 712-0798 Hex Nut 3/8-16 Thd.
—
770-8766K Owner's Manual
45 713-0433 Chain—^Tow Hitch
‘Common Hardware—May be Purchased Locally.
NOTEr Specifications subject to change without notice or obligation.
