BRIGGS AND STRATTON 5 H.P. ENGINE MODEL NO. 133402-0011-01
Repair Parts
^
_
REF.
NO.
PART
NO.
DESCRIPTION
1
495133
Cylinder Assembly
2
399268
Bushing-Cylinder
3
*299819
Seal-Oil
5
214040
Head-Cylinder
7
*272157
Gasket-Cylinder Head
8
495774
Breather-Valve Chamber
9
*27549
Gasket-Valve Cover
10
94621
Screw-Breather Mtg.
11
66578
Grommet-Breather Tube
13
94221
Screw-Cylinder Head (2-5/16" Long)
13A
94167
Stud-Cylinder Head
14
94679
Screw-Cylinder Head
(2-15/32“ Long)
15
94387
Plug-Pipe, 1/4" Std., Square Head
200
223886
Guide-Air
227
494906
Lever Assy.-Governor
230
94742
Washer-Governor Lever
305A
94786
Screw-Hex.Hd.
306
224820
Shield-Cylinder
307
94680
Screw-Cylinder Shield
308
224740
Cover-Cylinder Head
337
802592
Plug-Spark
383
89838
Wrench-Spark Plug
528
231818
Tube-Breather
552
231079
Bushing-Governor Crank
562
92613
Bolt-Governor Lever
592
231082
Nut-Hex.
614
93306
Cotter-Pin
616
231077
Crank-Governor
635
66538
Elbow-Spark Plug
869
211787
Seat-Intake Valve
870
211436
Seat-Exhaust Valve (Cobalite®)
871
262001
Guide-Exhaust Valve
Note:
63709 Guide-Intake Valve
978
*271736
Gasket-Cover
979
494807
Cover-Oil Gard®
982
94139
Screw-Oil Gard® Cover
1019
495861
Label Kit
REF.
NO.
PART
NO.
DESCRIPTION
75
495659
Washer Kit
98A
493280
Screw Assy.-Speed Adj.
165
94692
Nut-Wing
201
262865
Link-Governor
209
262283
Spring-Governor
222
494899
Plate-Gov. Control
232
260585
Spring-Link
284
94620
Screw-Hex. Hd.
346
93705
Screw-Sem
347
493521
Switch-Rocker
663
93343
Screw-Sem
984
224746
Bracket-Indicator Light
305A
1019 LABEL KIT
if
REQUIRES SPECIAL TOOLS
TO INSTALL. SEE REPAIR
INSTRUCTION MANUAL.
984
'Indyded in Gasket Set—Part No. 495661.
Assemblies Include all
22
