n^RTS MST
KEY PART
NO. NUMBER DESCRIPTION
1 97006078 Damper Aesembly (Includes Key Nos. 2 & 3)
a 98005221 Damper Flap
3 99100S79 Damper Bushing (2 Required)
4 99170245 #6-1 © X 3/8 Hex Head Sheet Metal Screws <18 Required}'
s 99110620 Louver Cover-Black
99110847 Louver Cover - White
99111038 Louver Cover - Almond
6 99090949 Kanmore Medallion - Black
9909094B Kenmoie Medallion - White
96090950 Kemnore MedallicHi - Almond
7 99271119 Ibuch Pad Switch * Black
99271118 Touch Pad Switch - White
99271120 Touch Pad Switch - Almond
8 97012388
97012391
97012394
97012389
97012392
Control Panel Assembly - Black ( 3 cr Wide Hoods) (Includes Key No. 7 )
Control Panel Assembly - White (30" wide Moods) (Intdudes Key No. 7)
Control Panel Assembly - Almond gGT Wide Hoods) (Includes Key No. 7}
Control Panel Assembly - Btadi (30r Wide Hoods) (Includes Key No. ^
Conbol Panel Assembly - White (36" Wide Hoods) (Includes Key No. 7)
97012395 Control Panel Assembly ■ Almond (se* Wide Hoods) (Inotudes Key No. 7)
97012390 Control Panel Assembly • Bleck (42* Wide Hoods) (InckKlss Key No. 7)
97012393 Control Panel Assembly - White (42" Wide Hoods) (includes Key No. 7)
97012396 Control Panel Assembly - Almond (42* Wide Hoods) (Includes Key No, 7)
9 97009092 Canopy - 3tr White (233.55346590)
97009093 Canopy-30" Almond
97010323 Canopy - 30" Stainless Steel
97012938 Canopy - 30" Black
97009094 Canopy • 36" White (233.55445590)
97009095 Canopy ■ 36* Almond
97010324 Canopy - 36" Stairiless Steel
07012939 Canopy - 36" Black
97009096 Canopy - 42" While {233.55546590}
97009097 Canopy • 42" Almond
97010325 Canopy - 42* Stainless Steel
97012940 Canopy - 42" Black
to 97007894 Aluminum niter Kit (Conleins 2 Piters)
11 9700799© Cleen Cooking System iV RIter Kit (Contains 2 Piteis)
12 99270754 Bulb Holder (2 Required)
13 97009091 Wire Hameea vnth Lamp Holders
14 99400042 Strain Relief Bushing
#10-32 X1/2 Creen Ground Screw* (4 Required)
15 99150471
16 97010824 Control Board Assembly
17 992S0945 washer
18 97009069 Wiring Box Cover
19 98007237 /\ccess Cover
20 99110605 Light Lens
21 96006546 Bulb Holder Cover
22 97007893 Bottom Cover - White
97007899 Bottom Cover - Almond
97007631 Bottom Cover - Stainless Steel
97011974 Bottom Cover - Black
23 99150478 #6-18x3% Phiilips Truss Head Screws (4 Rsquired)*
24 99260476 Blower Mounting Rod Nut (2 Required)
25 99420464 Blower Mounting Rod (2 Required)
26 97007314 Blower Scroll Housing
27 99020138 Blower Wheel, Clockwise
2S 98005212 Motor Retaining Ring (2 Required)
29 99100491 Rubber Motor Mount (4 Required)
30 97010736 Motor
31 99020139 Blower Wheel, Couniterdookwise
32
**
9701OJ27
99042171
Blower Assembly (Not Including Key Nos. 24 & 25)
Operating Instructions and Parte List
**
99042173 Installation Instruotlons
**
—— Light Bulb, 75 Watt Max. (2 Required) Not supplied with hood.
standard Hardware. May be purdnasad locally.
Not Illustrated.
