Sears 917.249391 User Manual
Page 9
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
1 1
M ount
top
cover
to
support
post
{Fig.
12)
using
hinge pin and retainer spring. R etainer spring show n
full size below , H inge pin and retainer spring furnish
ed w ith grass catcher.
1 2. P osition the grass catcher container assem blies on
to the support posts through the "L" slots (Fig. 13
- Inset).
TOP
COVER
RETAINER
SPRING
SUPPORT POST
F10URE 12
FIGURE 13
