Sears 917.255741 - Manual (Page 25)

REPAIR PARTS
ELECTRICAL
12 H.P. 38" RIDING LAWN TRACTOR-MODEL NUMBER 917.255741
fO
KEY
NO. PART
NO. OESCRIPTiON KEY
NO. PART
NO. DESCRIPTION
1 7662J Bulb, Light 17 719J Cover, Terminal
2 105386X Harness, Light Socket 18 5114J Cable, Battery
3 108865X Harness, Ignition 20 4207J Cable, Battery
4 105613X Key Set 21 STD522507 •Bolt, Hex. 1/4 -20x3/4
5 105381X Switch, Light 22 STD551025 •Washer 9/32 x 5/8 x 16 Ga.
6 104445X Switch. Interlock 23 STD541025 •Nut, Hex 1/4-20
7 3258J Nut, Hex 5/8-32 24 9272R Battery, 12V., Sears
8 11151000 Washer, Lock, Int, Tooth, 5/8 25 102476X Terminal Guard
9 ST0365402 Switch, Ignition 26 STD541625 •Wing Nut 1/4-20
10 108824X Fuse. 30 Amp. 27 11030400 lnt,/Ext. Tooth Lockwasher 1/4
11
12 STD551125
STD541225 ‘Washer. Lock, 1/4
•Nut. Hex Jam 1/4-20 28 72240460 Battery Bolt {Bolt - Carriage, Rd. Hd.
Sq. Neck 1/4 - 20 x 7 1/2)
13 STD522505 •Bolt, Hex, 1/4-20 X 1/2 Gr. 5 29 2008J Solenoid
14 73510400 Nut, Keps 1/4-20 32 7192J Cable Tie
15 108423X Cable Assembly 101539X Sheet - Instruction, Tractor 15° Slope
16 11050400 Washer Lock, Ext. Tooth, 1/4 ... 109034X Owners Manual
’STANDARD HARDWARE-PURCHASE LOCALLY
