12 H.P, 38" RIDING LAWN TRACTOR-MODEL NUMBER 917.255741
SCHEMATIC
-L
IGNITION SWITCH
STD365402
POSITION
CIRCUIT
OFF
M-G
ON
8-L
START
B-S
LIGHT
SWITCH
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED CLIPS
AND CABLE TIES WERE REMOVED FOR
SERVICING OF UNIT, THEY SHOULD
BE REPLACED TO PROPERLY SECURE
YOUR WIRING,
CHASSIS
GROUND
-23
