ECONOMIZER 5 CAS WATER HEATERS
MODEL NUMBERS:
153.333131 40 Gal.
153.333530 50 Gal.
153.333531 50 Gal
MODEL NUMBERS
KEY 153.333131 153.333530 153.333531
NO. PART DESCRIPTION PART NUMBERS
1 Temperature-Pressure Relief Valve 9000071 9000071 9000071
2 Primary Anode Rod 9000279 9000279 9000279
3 Model Rating Plate t 0270П8 0270118 0270118
4 Drain Valve 9000254 9000254 9000254
5 Drain Valve Washer {'%/ x x thick)** 9001584 9001584 9001584
6 Thermocouple Clip FI 45-0085 FI 45-0085 FI45-0085
7 Pilot FI 45-0609 9000284 FI 45-0609
8 Thermocouple* 42-9231 42-9231 42-9231
9 Pilot Tubing w/Fittings 9000278 9000278 9000278
10 Burner Orifice 0230129 0230129 0230129
Drill Size t#38) (#38) (#38)
11 Manifold 9001626 9001665 9001665
12 Burner 9000703 9000349 9000703
13 Outer Door 9000351 9000351 9000351
14 Inner Door 9000281 9000281 9000281
15 Gas Control Valve FI 45-0842 FI 45-0842 F145-0842
16 Temperature Adjustment Knob FI 45-0697 FI 45-0697 FI 45-0697
17 Dip Tube 9001852 9001852 9001852
18 Flue Baffle 9000360 9000360 9000360
19 Draft Hood 9000272 9000272 9000272
# Mag-Erad 3515
# Manual 0291348
* These parts are also available at most Sears retail stores
** Also available at most hardware stores,
tRepiaced only on return of damaged plate,
# Not Illustrated
Now that you have purchased your Gas Water Heater,
should a need ever exist for repair parts or service, simply
contact any Sears Service Center Be sure to provide all per­
tinent facts when you call or visit
All parts listed may be ordered from any Sears Service
Center and Most Sears stores
If the parts you need are not stocked locally, your order
will be electronically transmitted to a Sears Repair Parts
Distribution Center for handling.
The model number-of your Gas Water Heater will be
found on the model rating plate located above the gas
control valve,
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION:
MODEL NUMBER NAME OF ITEM
PART NUMBER PART DESCRIPTION
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
27
