ECONOMIZER«* 5 GAS WATER HEATERS
MODE! NUMBERS;
133.333000
153.333030
153.333031
153.333100
153,333130
30 Gal. High Altitude
30 Gal.
30 Gal.
40 Gai. High Altitude
40 Gal.
MODEL NUMBERS
KEY 153.333000 153.333030 153.333031 153.333100 153.333130
NO. PART DESCRIPTION PART NUMBERS
1 Temperature-Pressure Relief Valve 9000071 9000071 9000071 9000071 9000071
2 Primary Anode Rod 9000279 9000279 9000279 9000279 9000279
3 Model Rating Plate t 0270118 0270118 0270118 0270118 0270118
4 Drain Valve 9000254 9000254 9000254 9000254 9000254
s Drain Valve Washer ('¥«“ x x ’// thick!** 9001584 9001584 9001584 9001584 9001584
6 Thermocouple Clip F145-0085 FI 45-0085 FI 45-0085 FI 45-0085 FI45-0085
7 Pitot 9000284 9000284 FI 45-0609 9000284 9000284
8 Thermocouple* 42-9231 42-9231 42-9231 42-9231 42-9231
9 Pilot Tubing w/Fittings 9000278 9000278 9000278 9000278 9000278
10 Burner Orifice 0230181 0230182 0230182 0230122 0230129
Drill Size (#43)HA {#40) (#40) (#41 )HA (#38)
11 Manifold 9000739 9000739 9000739 9001626 9001626
12 Burner 9000349 9000349 9000703 90Q0349 9000349
13 Outer Door 9000351 9000351 9000351 9000351 9000351
14 Inner Door 9000281 9000281 9000281 9000281 9000281
15 Gas Control Valve FI 45-0842 FI 45-0842 FI 45-0842 F14S-0842 FI 45-0842
10 Temperature Adjustment Knob FI 45-0697 FI 45-0697 FI 45-0697 F14S-0697 FI 45-0697
17 Dip Tube 9001852 9001852 9001852 9001852 9001852
18 Flue Baffle 9000360 : 9000360 9000360 9000360 9000360
19 Draft Hood 9000272 i 9000272 9000272 9000272 9000272
# Mag-Erad 3515
# Manual 0291348
* These parts are also available at most Sears retail stores.
** Also available at most hardware stores
tRepiaced only on return of damaged plate.
# Not Illustrated
Now that you have purchased your Gas Water Heater,
should a need ever exist for repair parts or service, simply
contact any Sears Service Center
8 e sure to provide all per­
tinent facts when you call or visit
All parts listed may be ordered from any Sears Service
Center and Most Sears stores
If the parts you need are not stocked locally, your order
will be electronically transmitted to a Sears Repair Parts
Distribution Center for handling.
The model number of your Gas Water Heater will be
found on the model rating plate located above the gas
control valve-
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION:
MODEL NUMBER NAME OF ITEM
PART NUMBER PART DESCRIPTION
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
