TROUBLESHOOTING CHART
TROUBLE PROBABLE CAUSE REMEDY
Noisy operation 1 Incorrect V-belt tension.
2, Dry spindle shaft.
3. Loose Spindle shaft or
Motor Pulley
1. Adjust tension
2 . Lubricate spindle shaft. See “Maintenance”
section.
3. Tighten Lock Nut (left hand thread) or pulley
set screw.
Bit burns or smokes 1. incorrect spindle speed.
2 Chips not coming out of hole
3. Dull bit.
4 Feed rate too slow.
5. Bit not lubricated (metai working).
1. Change spindle speed.
2. Retract bit frequently to dear chips
3. Sharpen or replace bit.
4. Feed faster.
5. Lubricate bit.
Excessive drill bit
runout or wobble 1. Bent bit
2. Chuck not properly installed.
3. Bit not properly installed.
4. Worn or loose chuck.
5. Worn spindle bearings
1. Replace bit.
2. Remove chuck and install properly.
3 Remove bit and install properly.
4 Replace chuck
5. Replace bearings.
Drill binds in
workpiece
1. Improper V-beit tension,
2. Workpiece twisting or moving
3. Excessive feed pressure.
1. Adjust V-belt tension.
2. Support or clamp workpiece.
3 Reduce pressure and clamp workpiece,
Workpiece torn
loose from hands 1 Not properly supported or
clamped.
1. Support and clamp workpiece
Owner’s
Manual
SERVICE
MODEL NO.
149.213340
34-INCH RADIAL DRILL PRESS
Now that you have purchased your Radial Drill Press should a need ever
exist for repair parts or service, simply contact any Sears Service'Center
or most Sears, Roebuck and Co, stores. Be sure to provide all pertinent
facts when you call or visit.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING
INFORMATION:
PART NUMBER
MODEL NUMBER
149,213340
• PART DESCRIPTION
• NAME OF ITEM:
34-INCH RADIAL DRILL PRESS
All parts listed may be ordered from any Sears Service Center and most
Sears stores.
If the parts you need are not stocked locally, your order will be electroni­
cally transmitted to a Sears Repair Parts Distribution Center for handling.
SEARS, ROEBUCK AND CO., Hoffman Estates, IL 60179, U.S.A.
Printed in U.S.A.
