CRAFTSMAN 1800 PSI HIGH PRESSURE WASHER 580.751510
BRIGGS & STRATTON 4-CYCLE ENGINE 133212-0159-01
REPAIR PARTS
No.
Part
No.
Part Name
1
49S133
Cytinctei* Assembly
3
«34 A
Oil S
gg
I
5
214040
CyllitdsrHsad
7
*272157
Cylindaf Haaef Saskat
a
294178
Bisather - Valve Chamber
9
•27459
Valve Cover Gasimt
10
94821
Screw - Breather Mounting Sam
11
66578
Breather Tube Grommet
12
*270W0
13
94221
Cylinder Head Screw—2*3/32“
13A
941^3
Cylinder Head Stud
14
94678
Cylinder Head Screw
15
94387
Oil Drain Plug (magnetic)
18
495845
Crankahaft
NOTE; To replace crankahaft pin,
order Part No. 230978
17
494874
Ball Bearing (PTO aide)
18
495841
Crankcase Cover Assembly
19
495860
Bushing — Oil Seal
m
*495307
Oil Seal
21
66768
Oil Filler Plug
22
94682
Hex Head Screw
23
297229
Flywheel
24
222696
Flywheel Key
25
393819
Platon Assembly
399087
Ring Set
27
28026
Piston Pin Lock
28
298909
Piston Pin Assembly
29
299430
Connecting Rod Assembly
221890
Connecting Rod Dipper
94746
Connecting Rod Screw
33
262464
Exhaust Valve
34
261044
Intake Valve
35
260552
Intake Valve Spring
38
282750
Exhaust Valve Spring
37
222443
Flywheel Guard
40
93312
Valve Spring Retainer
41
49'i 442
Retainer Valve
45
260642
Valve Tappet
46
212733
Cam Gear
52
* 1:271938
Carburetor Mounting Gasket
55
494846
Rewind Starting Housing
58
493^4
Rewind Starter Pulley
57
262594
Rewind Starter Spring
58
280406
Rewind Starter Rope (cut 1o length)
59
396892
80
393152
Rewind Starter Handle
94lH3b
Housing Mounting Screw
69
280973
Washer
S9A
224322
Washer
73
224833
Rotating Screen
75
224061
Flywheel Washer
81
222263
Screw Lock
90
49S426
Carburetor Assembly
95
93499
Throttlo*Vaive*io-Shatt Screw
96
223793
Carburetor Throttle
97
490048
Throttle Shaft and Lever
108
491177
Choke Valve Group
118
231533
Needle Valve
121
495606
Carburetor Kit
124
94616
Hex Head Screw
127
220352
Welch Plug
127A
nfcuCOI ffJVt
Welch Plug (Mixing Chamber)
149
Needle Valve Spring
152
26057S
Throttle Adjustment Spring
153
49DSS9
Screw and Collar
154
93S27
Round Head Screw 5-40 x 5/8“
Ref.
No.
No.
Port Nsnrto
163
*271935
Air Cleaner Mounting Gasket
180
495405
Fuel Tank Assembly
181
494559
Fuel Tank Cap
187
231068
Fuel Pipe
190
94712
Screw - Sem
190A
94677
Screw - Sem
191
r272489
Fuel Tank Mounting Gasket
201
262280
Governor Link
202
Throttle Link
203
280720
Bell Crank
204
222962
Control Lever Bushing
2m
231520
Shoulder Screw
208
94081
Stop Nut
2(yT
26855
Control Rod Spring
208
262323
Speed Control Rod
209
262282
Governor Spring
216
262359
Choke Lilnk
217
262281
Choke Spring
219
391737
Governor Gear
220
2215S1
Thrust Washer
222
490649
Control Bracket
223
223455
Governor Control Lever
224
93491
Governor Control Lever Rivet
227
490374
Governor Lever Assembly
230
222450
Governor Lever Washer
232
262310
Return Spring
256
223813
Sell Crank
Casing Clamp
267
93496
w Ini
266
66986
Control Wire Casing — 48“ tong
If longer casing is needed, specify
ienght In inches; If shorter casing is
needed, order No. €6986 and cut to
required length.
269
26099
Control Wire
270
63426
Casing Locknut
271
290568
Control Levar
280
Control Rod Bracket
300A
393615
Exhaust Muffler.
304
495795
Blower Housing
305
94619
Blower Housing Mounting Screw
306
224820
Cylinder Shield
308
224738
Cylinder Head Cover
332
92284
Flywheel Nut
f vf-MM
Armature Assembly
334
93613
Sem Screw
335
93414
Armature Mounting Screw
337
492167
Spark Plug — 1-7/8" high, 48mm
346
94680
Screw
346A
93705
Screw
353
92791
Lock Washer
354
90578
Hex Nut
356
398803
Ground Wire
358
495603
Gasket Set
38J
19053
Flywheel Puller
373
92987
Hex Nut
392
2!62!32d
Diaphragm Spring
394
4272538
Diaphragm
• Included in Gasket Set — Part No. 495603
t
Included in Carturelor Kit — Part No. 495606
