Table of Contents
FCC Compliance statement for American Users. . . i
EMI Compliance Statement for Canadian Users . . . ii
Important Safety Instructions................ill
Notice .............................................iv
Safety Signs .....................................v
Warning....... ............. ..................... vi
General precautions........................... vii
Precautions when installing the printer viii
Chapters in this Manual , , . . . . . . . . . . . . . . . ix
Chapter 1 Setup......................... .. ............ 1-1
1.1 Confirmation of Carton Contents..... 1-2
1.2 Installing the paper holders. . . . :....1-3
1.2 Names and Functtons of the Parts . . . . . . . 1-4
1.3 Connection to Power . . . . . . . . . . . . . . . 1-8
1.4 Connection to a Computer............. 1-9
Chapter 2 Control Panel.............. .. 2-1
2.1 Control Panel............................... 2-2
Chapter 3
Chapter 4
2.2 LCD/LED Indications
and Adjustment Contiois........... . . 2-3
2.3 Normal Operating Mode............ . . 2-3
2.4 Printer Setup Mode.................. . 2-4
2.5 Self-Test Mode ......... .............. . 2-4
2.6 System Mainitenance Mode......... . . 2-5
3 Paper and ribbon. . . .. . . ... . . 3-1
3.1 Kinds of Paper..................... . . 3-2
3.2 Label and Tag Specifications....... . . 3-2
3.3 Ribbon.................................. . . 3-6
3.4 Loading the Paper.................... . . 3-7
3.5 Loading the Ribbon................... , . 3-9
3.6 Print Head Offset Adjustments.... . . 3-10
3.7 R№on Tension Adjustments........ . . 3-12
4 Troubleshooting...................... . 4-1
4.1 Error Messages........................ . . 4-2
4.1.1Error descriptions and indications. . . 4-2
4.1.2Error indications and corrective actions. . . . 4-4
4.2 Power Troubleshooting............. . . 4-7
4.3 Paper Feed Troubleshooting....... . . 4-8
4.4
4.5
4.6
Ribbon Feed Troubleshooting
Print Troubleshooting.. 4-9
4-10
Interface Troubleshooting.............. 4-11
