HORiZONTAL FURNACE COMPONENTS
\ I i Gas valve. Safe, efficient. Features two separate
gas shut-off valves.
I 2 I Burner assembly (inside). Operates with hot
surface ignitor, inshot burners, and flame sensor
for safe, dependable heating.
I
3 ~| Primary serpentine heat exchanger (inside).
Stretches fuel dollars with the S-shaped heat
flow design. Solid construction of corrosion-
resistant aluminized steel means reliability.
I
4 I Secondary condensing heat exchanger (inside).
Wrings out more heat through condensation.
Constructed with corrosion-resistant steel to
ensure durability.
I
5 1 Inducer motor. Pulls hot flue gases through the
heat exchangers, maintaining negative pressure
for added safety.
I 6 I Vent outlet. Uses PVC pipe to carry vent gases
from the home.
I
7 1 Condensate drain trap. Collects moisture
condensed from burned gases for disposal into
home drain system.
Heavy-duty blower (inside). Circulates air,
scrubbing the heat exchangers to speed
condensation and transfer extra heat into the
home.
I
9 [ Air filter and wire filter retainer (inside).
A91174
MODEL 58EJA HORIZONTAL FURNACE
