ESPECIFICACIONES (1K-HB / 2K-HB / 3K-HB) (1/2)
OPTIMA (HB)
INPUT / ENTRADA
Freq. Range / Rango Frecuencia
Slew Rate / Seguimiento de F.
Surge Immunity Level
Output Regulation / Rango de Salida
Freq. Conversion / Conversión Frec.
EPO /Apagado Emergencia
Progammable Outputs / Salidas Prog.
Eco Mode
AC Mode / Modo Normal
Battery Mode / Modo Batería
Output Shortcircuit / Cortocircuito en Salida
Type / Tipo
Cap. & Qty
Recharge Time / Recarga
Charging Voltage / Voltaje de Carga
Charging Amps / Corriente de Carga
EXT. BATT CABINETS (Optional) - BATERIAS EXTERNAS (opcionales)
Standard EXT-BATT pack
INDICATORS / INDICADORES
LCD
UPS status, Load level, Battery, Input/Output voltage, Discharge timer, and Fault conditions
Estado del UPS, Consumo, Baterías, Voltaje Entrada/Salida, Autonomía, Diagnostico Fallas
ALARM / ALARMAS
Alarm Beep / Alarma Sonora:
Battery Mode, Low batt., Overload, UPS Failure / Modo Batería, Baja batería, Sobrecargas, Falla
4 Hours for 90% capacity / 4 Horas para recuperar el 90% de carga
27.4Vdc 54.7Vdc 82.1Vdc
1.0 A (Max.)
x 12V-9Ah x 8 12V-9Ah x 12
Full Protection for all outlets / Protección en todas las salidas
105%~110%: 10 min: shutdown / 110%~130%: 1 min: shutdown / >130% : 3s: shutdown
BATTERIES / BATERIAS
Sealed Lead Acid VRLA-AGM / Sellada de Libre Mantenimiento VRLA-AGM
12V/9AH x 2 12V/9AH x 4 12V/9AH x 6
Battery Mode / Modo Batería > 86% > 88% > 88%
OVERLOAD/ SOBRECARGA
105%~110%: 10 min to Bypass / 110%~130%: 1min to Bypass / >130% : 3s: bypass
PEAK EFFICIENCY / EFICIENCIA MAX.
> 93% > 93% > 93%
AC Mode / Modo AC > 89% > 90% > 90%
N N N
N N N
AC to Inverter / Tiempo AC a Inversor 0 ms
Waveform / Forma de Onda Pure Sinewave / Sinusoidal Pura
N N N
+/-1% (in Batt. mode)
Frequency / Frecuencia (Batt. Mode) (*N3) 50 Hz +/- 0.25 Hz - 60Hz +/- 0.3 Hz
Current Crest Ratio / Factor de Cresta 3:1 @ 100% load
Harmonic Distortion /
Dist. Armónica (THDv) < 3% @ Linear Load / Carga Lineal
<6% @ No Linear Load / Carga no Lineal
Input THDi / THDi de Entrada < 7% @ 100% load
1 Hz / s
> 7KV (EN61000-4-5)
OUTPUT / SALIDA
Voltage Output / Voltaje de Salida AC
(*N1) Model 120V: 110/115/120/127Vac - Model 220V: 208/220/230/240Vac
Range / Rango - Vac (Models 220V):
Model 220V: 160Vac-290Vac (load @ 100%)
Model 220V: 110Vac-300Vac (load @ 50%)
40 Hz - 70Hz
Phase / Fases Single phase with ground / 1 fase + Tierra
Power Factor / Factor de Potencia > 0.99 @ 100% load
Capacity / Capacidad (W) 800W 1600W 2400W
Range / Rango - Vac (Models 120V):
Model 120V: 85Vac -145Vac (load @ 100%)
Model 120V: 55Vac -150Vac (load < 50%)
ONLINE UPS (1/2) 1K-HB 2K-HB 3K-HB
Capacity / Capacidad (VA) 1000VA 2000VA 3000VA
