P130 operators manual ISSUE 2 14/6/04 AM 6
3.2 INPUT CONFIGURATION
Configuration of the expansion inputs is performed by configuring the master controller module.
This instructs the controller how to interface with the expansion modules. The input expansion
module is not directly configurable.
For further details on module configuration, you are referred to the relevant configuration software
manual.
3.3 PANEL LAYOUT
Connector 1
Connector 2 To ‘ host ’
controller
Further
expansion
Power on LED
Cable fault LED
