P130 operators manual ISSUE 2 14/6/04 AM 10
4.1.2 REAR PANEL LAYOUT
4.2 TERMINAL DESCRIPTION
4.2.1 CONNECTOR 1
PIN No DESCRIPTION CABLE SIZE NOTES
A 0V 0.5mm 2
B A 0.5mm 2
C B 0.5mm 2
D +12V 0.5mm 2
Thinner cable will reduce the maximum
allowable cable length
CAUTION!: Connector 1 is only intended for connection to the DSE 549 annunciator.
Connection to any other device may cause damage and will invalidate the warranty.
Connector 1
