P130 operators manual ISSUE 2 14/6/04 AM 11
4.2.2 TYPICAL CONNECTION SCHEMATICS :
NOTE:- Previously, the 53xx expansion port was used solely for output expansion.
For this reason, modules manufactured prior to the release of the P130 input
expansion module may be marked as :
157/548
These
‘
earl
y’
modul
es
are
not
compati
bl
e
wi
th
the
P130
i
nput
expansi
on
modul
e.
4.3 549 REMOTE ANNUNCIATOR SPECIFICATION
DC Supply
8.0 to 35 V Continuous.
Cranking Dropouts
Able to survive 0 V for 50 mS, providing supply was at least
10 V before dropout and supply recovers to 5V
Max. Operating Current
150mA at 12V. 81mA at 24V. This maximum current includes the
P130, which provides power to the P549.
Dimensions
171mm
x
115mm
x
49mm
(
6¾”
x
4½”
x
2”
)
Operating Temperature Range
-30°C to +70°C
IP Rating of P549 fascia
IP55 when fitted into control panel with supplied gasket
Connector 1 max cable length to
P130 input expansion module
1000m with cable of 0.5mm
2
cross section
500m with cable of 0.2mm
2
cross section (typical 4 core
burglar alarm/telephone wire)
4.4 TYPICAL WIRING DIAGRAM
P810 interface
and cable
Expansion cable
5300 series
Expansion cable
To further
expansion
(157/548)
549 Remote Annunciator
Configuration / monitoring PC
Expansion
cable
548 annunciator
OR
130 Input Expansion
