20
OPTIONS PROGRAMMING Cont.
To Engage Option Programming:
1. Open hood (If no hood pin switch is installed, then ground the Blue wire)
2. Turn Key to the ON position. (Do not start vehicle) Pink wire must be connected!
3. Press the program / valet button 5 times. Wait for the unit to flash the lights and/or horn honk 5 times.
4. Push the valet/program button the number of times that corresponds to the option number desired (1-22X). You
must get a light flash and/or honk after each button press. If the system did not flash the lights and/or honk,
then it did not register your press. Press carefully and do not lose count.
5. When you reach the desired option #, Press button #1(Lock) or #2 (Unlock) to change the option. (Some
option numbers use ALL 4 remote buttons to select settings)
6. When finished, turn Ignition OFF, close hood (or un-ground Blue wire) and check for changed features.
OPTION PROGRAMMING TABLE
Option
Number
Option Description TX Button #1 TX Button #2 TX Button #3 TX Button #4
1 Engine Monitoring Learn Tach *Tachless*
2 Auto Lock with RPM/Ignition ON *OFF*
3 Door Lock Pulse Time 3 Sec. *0.75 Sec.*
4 Double Unlock Pulse 2 Pulse *1 Pulse*
5 OEM Interface Green input wire 3 Pulse *1 Pulse*
6
Double button press for
Remote Start and Trunk pop
ON *OFF*
7 Horn Chirps on Remote Start ON *OFF*
8 Lock After Remote Start/Abort OFF *ON*
9 Green/red wire function Dome Light *Trunk pop*
10
“Wake Up" pulse on Unlock
(1-sec. +12V to IGN)
ON *OFF*
11 N/A - Not used
