FS2620R Rack Model User’s Guide
2-10
Router Default Settings
Table 2-3 below lists the router default settings. If these settings meet your needs, you can
use your router now. If they do not, you can change the settings. See
Chapter 3,
Configuring the Router .
Table 2-3. Router default settings
Setting Default For more information, see
Mapping Mode AUTO Changing the Mapping Mode (AUTO or
FIXED) on page 3-24
Topology LOOP Configuring the FC Host Channels on
page 3-12
Router’s loop ID SOFT Configuring the FC Host Channels on
page 3-12
Router’s LUN SOFT Configuring the FC Host Channels on
page 3-12
Router’s initiator ID
(SCSI ID) on each
channel 7 Changing the SCSI ID Assigned to Each
Router Channel on page 3-17
Scan Delay 0 seconds Changing the Scan Delay on page 3-21
Alarm ENABLE
D Enabling and Disabling the Alarm on
page 3-21
Link Speed 1 GB Configuring the FC Host Channels on
page 3-12
